Список основных команд необходимых для выполнения лабораторной
работы приводится в таблице 11.
Таблица 11 – Основные команды для лабораторной работы № 11
Команда Описание
(config-router) distance ospf {[intra-
area dist1] [inter-area dist2] [external
dist3]}
Установка административного
расстояния для протокола OSPF.
(config-router)# distance distance Установка административного
расстояния для протокола RIP.
(config-router)# distance eigrp
internal-distance external-distance
Установка административного
расстояния для протокола EIGRP.
121
Задание 1. Изучение совместной работы протоколов маршрутизации
В этом задании необходимо рассмотреть совместную работу протоколов
маршрутизации RIP, EIGRP и OSPF.
Шаг 1
Посмотрите таблицы маршрутизации на маршрутизаторах стенда.
r1#show ip route
.. .. ..
172.16.0.0/28 is subnetted, 2 subnets
C 172.16.0.16 is directly connected, Serial0/0/1
C 172.16.0.0 is directly connected, Serial0/0/0
10.0.0.0/8 is variably subnetted, 30 subnets, 2 masks
R 10.89.2.80/28 [80/2] via 172.16.0.18, 00:00:24, Serial0/0/1
R 10.89.1.80/28 [80/2] via 172.16.0.2, 00:00:01, Serial0/0/0
R 10.89.2.64/28 [80/2] via 172.16.0.18, 00:00:25, Serial0/0/1
R 10.89.1.64/28 [80/2] via 172.16.0.2, 00:00:02, Serial0/0/0
R 10.89.2.112/28 [80/2] via 172.16.0.18, 00:00:25, Serial0/0/1
R 10.89.1.112/28 [80/2] via 172.16.0.2, 00:00:02, Serial0/0/0
R 10.89.2.96/28 [80/2] via 172.16.0.18, 00:00:26, Serial0/0/1
R 10.89.1.96/28 [80/2] via 172.16.0.2, 00:00:04, Serial0/0/0
R 10.89.2.16/28 [80/2] via 172.16.0.18, 00:00:26, Serial0/0/1
R 10.89.1.16/28 [80/2] via 172.16.0.2, 00:00:04, Serial0/0/0
R 10.93.2.16/28 [80/1] via 172.16.0.18, 00:00:26, Serial0/0/1
R 10.93.1.16/28 [80/1] via 172.16.0.2, 00:00:04, Serial0/0/0
R 10.95.2.7/32 [80/2] via 172.16.0.18, 00:00:26, Serial0/0/1
R 10.95.1.4/32 [80/2] via 172.16.0.2, 00:00:04, Serial0/0/0
R 10.95.2.6/32 [80/2] via 172.16.0.18, 00:00:26, Serial0/0/1
R 10.95.1.5/32 [80/2] via 172.16.0.2, 00:00:04, Serial0/0/0
R 10.89.2.0/28 [80/2] via 172.16.0.18, 00:00:26, Serial0/0/1
R 10.89.1.0/28 [80/2] via 172.16.0.2, 00:00:05, Serial0/0/0
C 10.89.0.0/28 is directly connected, FastEthernet0/1.801
R 10.95.2.3/32 [80/1] via 172.16.0.18, 00:00:00, Serial0/0/1
C 10.95.0.1/32 is directly connected, Loopback0
R 10.93.2.0/28 [80/1] via 172.16.0.18, 00:00:00, Serial0/0/1
R 10.95.1.2/32 [80/1] via 172.16.0.2, 00:00:05, Serial0/0/0
R 10.93.1.0/28 [80/1] via 172.16.0.2, 00:00:05, Serial0/0/0
R 10.89.2.48/28 [80/2] via 172.16.0.18, 00:00:00, Serial0/0/1
R 10.89.1.48/28 [80/2] via 172.16.0.2, 00:00:06, Serial0/0/0
R 10.89.2.32/28 [80/2] via 172.16.0.18, 00:00:01, Serial0/0/1
R 10.89.1.32/28 [80/2] via 172.16.0.2, 00:00:06, Serial0/0/0
R 10.93.2.32/28 [80/2] via 172.16.0.18, 00:00:01, Serial0/0/1
R 10.93.1.32/28 [80/2] via 172.16.0.2, 00:00:06, Serial0/0/0
r2#show ip route
.. .. ..
172.16.0.0/28 is subnetted, 2 subnets
R 172.16.0.16 [80/1] via 172.16.0.1, 00:00:14, Serial0/0/0
C 172.16.0.0 is directly connected, Serial0/0/0
10.0.0.0/8 is variably subnetted, 30 subnets, 2 masks
R 10.89.2.80/28 [80/3] via 172.16.0.1, 00:00:14, Serial0/0/0
R 10.89.1.80/28 [80/1] via 10.93.1.18, 00:00:17, Serial0/1/0
R 10.89.2.64/28 [80/3] via 172.16.0.1, 00:00:15, Serial0/0/0
R 10.89.1.64/28 [80/1] via 10.93.1.18, 00:00:18, Serial0/1/0
R 10.89.2.112/28 [80/3] via 172.16.0.1, 00:00:15, Serial0/0/0
R 10.89.1.112/28 [80/1] via 10.93.1.18, 00:00:18, Serial0/1/0
R 10.89.2.96/28 [80/3] via 172.16.0.1, 00:00:16, Serial0/0/0
R 10.89.1.96/28 [80/1] via 10.93.1.18, 00:00:19, Serial0/1/0
R 10.89.2.16/28 [80/3] via 172.16.0.1, 00:00:16, Serial0/0/0
R 10.89.1.16/28 [80/1] via 10.93.1.2, 00:00:12, Serial0/0/1
122
R 10.93.2.16/28 [80/2] via 172.16.0.1, 00:00:16, Serial0/0/0
C 10.93.1.16/28 is directly connected, Serial0/1/0
R 10.95.2.7/32 [80/3] via 172.16.0.1, 00:00:16, Serial0/0/0
R 10.95.1.4/32 [80/1] via 10.93.1.2, 00:00:12, Serial0/0/1
R 10.95.2.6/32 [80/3] via 172.16.0.1, 00:00:16, Serial0/0/0
R 10.95.1.5/32 [80/1] via 10.93.1.18, 00:00:19, Serial0/1/0
R 10.89.2.0/28 [80/3] via 172.16.0.1, 00:00:16, Serial0/0/0
R 10.89.1.0/28 [80/1] via 10.93.1.2, 00:00:12, Serial0/0/1
R 10.89.0.0/28 [80/1] via 172.16.0.1, 00:00:17, Serial0/0/0
R 10.95.2.3/32 [80/2] via 172.16.0.1, 00:00:17, Serial0/0/0
R 10.95.0.1/32 [80/1] via 172.16.0.1, 00:00:17, Serial0/0/0
R 10.93.2.0/28 [80/2] via 172.16.0.1, 00:00:17, Serial0/0/0
C 10.95.1.2/32 is directly connected, Loopback0
C 10.93.1.0/28 is directly connected, Serial0/0/1
R 10.89.2.48/28 [80/3] via 172.16.0.1, 00:00:17, Serial0/0/0
R 10.89.1.48/28 [80/1] via 10.93.1.2, 00:00:16, Serial0/0/1
R 10.89.2.32/28 [80/3] via 172.16.0.1, 00:00:19, Serial0/0/0
R 10.89.1.32/28 [80/1] via 10.93.1.2, 00:00:16, Serial0/0/1
R 10.93.2.32/28 [80/3] via 172.16.0.1, 00:00:19, Serial0/0/0
R 10.93.1.32/28 [80/1] via 10.93.1.18, 00:00:23, Serial0/1/0
[80/1] via 10.93.1.2, 00:00:16, Serial0/0/1
r4#show ip route
.. .. ..
172.16.0.0/28 is subnetted, 2 subnets
R 172.16.0.16 [80/2] via 10.93.1.1, 00:00:18, Serial0/0/0
R 172.16.0.0 [80/1] via 10.93.1.1, 00:00:18, Serial0/0/0
10.0.0.0/8 is variably subnetted, 30 subnets, 2 masks
R 10.89.2.80/28 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.89.1.80/28 [80/1] via 10.93.1.34, 00:00:00, FastEthernet0/0
R 10.89.2.64/28 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.89.1.64/28 [80/1] via 10.93.1.34, 00:00:00, FastEthernet0/0
R 10.89.2.112/28 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.89.1.112/28 [80/1] via 10.93.1.34, 00:00:00, FastEthernet0/0
R 10.89.2.96/28 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.89.1.96/28 [80/1] via 10.93.1.34, 00:00:00, FastEthernet0/0
R 10.89.2.16/28 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
C 10.89.1.16/28 is directly connected, FastEthernet0/1.812
R 10.93.2.16/28 [80/3] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.93.1.16/28 [80/1] via 10.93.1.34, 00:00:00, FastEthernet0/0
[80/1] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.95.2.7/32 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
C 10.95.1.4/32 is directly connected, Loopback0
R 10.95.2.6/32 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
R 10.95.1.5/32 [80/1] via 10.93.1.34, 00:00:00, FastEthernet0/0
R 10.89.2.0/28 [80/4] via 10.93.1.1, 00:00:18, Serial0/0/0
C 10.89.1.0/28 is directly connected, FastEthernet0/1.811
R 10.89.0.0/28 [80/2] via 10.93.1.1, 00:00:22, Serial0/0/0
R 10.95.2.3/32 [80/3] via 10.93.1.1, 00:00:22, Serial0/0/0
R 10.95.0.1/32 [80/2] via 10.93.1.1, 00:00:22, Serial0/0/0
R 10.93.2.0/28 [80/3] via 10.93.1.1, 00:00:22, Serial0/0/0
R 10.95.1.2/32 [80/1] via 10.93.1.1, 00:00:22, Serial0/0/0
C 10.93.1.0/28 is directly connected, Serial0/0/0
R 10.89.2.48/28 [80/4] via 10.93.1.1, 00:00:22, Serial0/0/0
C 10.89.1.48/28 is directly connected, FastEthernet0/1.814
R 10.89.2.32/28 [80/4] via 10.93.1.1, 00:00:22, Serial0/0/0
C 10.89.1.32/28 is directly connected, FastEthernet0/1.813
R 10.93.2.32/28 [80/4] via 10.93.1.1, 00:00:22, Serial0/0/0
C 10.93.1.32/28 is directly connected, FastEthernet0/0.311
Почему в таблице маршрутизации присутствуют только маршруты
полученные от протокола RIP?
123
Шаг 2
Посмотрите режим работы протоколов маршрутизации.
r2#show ip protocols
Routing Protocol is "eigrp 200"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Default networks flagged in outgoing updates
Default networks accepted from incoming updates
EIGRP metric weight K1=1, K2=0, K3=1, K4=0, K5=0
EIGRP maximum hopcount 100
EIGRP maximum metric variance 1
Redistributing: eigrp 200
EIGRP NSF-aware route hold timer is 240s
Automatic network summarization is not in effect
Maximum path: 4
Routing for Networks:
10.93.1.0/27
10.95.1.2/32
172.16.0.0/28
Passive Interface(s):
FastEthernet0/0
FastEthernet0/1
Serial0/1/1
Loopback0
VoIP-Null0
Routing Information Sources:
Gateway Distance Last Update
10.93.1.18 90 00:08:37
10.93.1.2 90 00:08:37
172.16.0.1 90 00:08:37
Distance: internal 90 external 170
Routing Protocol is "ospf 1"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Router ID 2.2.2.2
Number of areas in this router is 1. 1 normal 0 stub 0 nssa
Maximum path: 4
Routing for Networks:
10.93.1.0 0.0.0.31 area 1
10.95.1.2 0.0.0.0 area 1
172.16.0.0 0.0.0.15 area 1
172.16.0.32 0.0.0.15 area 1
Reference bandwidth unit is 100 mbps
Passive Interface(s):
FastEthernet0/0
FastEthernet0/1
Serial0/1/1
Loopback0
Passive Interface(s):
VoIP-Null0
Routing Information Sources:
Gateway Distance Last Update
3.3.3.3 110 00:14:56
6.6.6.6 110 00:13:34
4.4.4.4 110 00:13:59
1.1.1.1 110 00:21:43
7.7.7.7 110 00:13:34
5.5.5.5 110 00:13:59
Distance: (default is 110)
124
Routing Protocol is "rip"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Sending updates every 30 seconds, next due in 13 seconds
Invalid after 180 seconds, hold down 180, flushed after 240
Redistributing: rip
Default version control: send version 2, receive version 2
Interface Send Recv Triggered RIP Key-chain
Serial0/0/0 2 2
Serial0/0/1 2 2
Serial0/1/0 2 2
Automatic network summarization is not in effect
Interface Send Recv Triggered RIP Key-chain
Maximum path: 4
Routing for Networks:
10.0.0.0
172.16.0.0
Passive Interface(s):
FastEthernet0/0
FastEthernet0/1
Serial0/1/1
Loopback0
VoIP-Null0
Routing Information Sources:
Gateway Distance Last Update
10.93.1.18 80 00:00:24
10.93.1.2 80 00:00:21
172.16.0.1 80 00:00:24
Distance: (default is 80)
Чтобы ответить на ранее поставленный вопрос, обратите внимание на
выделенные строки.
Задание 2. Переход с протокола маршрутизации RIP на протокол
EIGRP.
В этом задании необходимо перейти с маршрутизации по протоколу RIP
на маршрутизацию по протоколу EIGRP.
Шаг 1
На маршрутизаторе R1 измените административное расстояние для
протокола RIP на его административное расстояние по умолчанию.
Шаг 2
Убедитесь, что административное расстояние сменялось.
r2#show ip protocols rip
Routing Protocol is "rip"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Sending updates every 30 seconds, next due in 13 seconds
Invalid after 180 seconds, hold down 180, flushed after 240
Redistributing: rip
Default version control: send version 2, receive version 2
Interface Send Recv Triggered RIP Key-chain
Serial0/0/0 2 2
125
Serial0/0/1 2 2
Serial0/1/0 2 2
Automatic network summarization is not in effect
Interface Send Recv Triggered RIP Key-chain
Maximum path: 4
Routing for Networks:
10.0.0.0
172.16.0.0
Passive Interface(s):
FastEthernet0/0
FastEthernet0/1
Serial0/1/1
Loopback0
VoIP-Null0
Routing Information Sources:
Gateway Distance Last Update
10.93.1.18 120 00:00:24
10.93.1.2 120 00:00:21
172.16.0.1 120 00:00:24
Distance: (default is 120)
Шаг 3
Посмотрите таблицу маршрутизации маршрутизатора R1.
r1#show ip route
.. .. ..
172.16.0.0/28 is subnetted, 2 subnets
C 172.16.0.16 is directly connected, Serial0/0/1
C 172.16.0.0 is directly connected, Serial0/0/0
10.0.0.0/8 is variably subnetted, 30 subnets, 2 masks
O 10.89.2.80/28 [110/101] via 172.16.0.18, 00:00:47, Serial0/0/1
O 10.89.1.80/28 [110/101] via 172.16.0.2, 00:00:47, Serial0/0/0
O 10.89.2.64/28 [110/101] via 172.16.0.18, 00:00:47, Serial0/0/1
O 10.89.1.64/28 [110/101] via 172.16.0.2, 00:00:48, Serial0/0/0
O 10.89.2.112/28 [110/101] via 172.16.0.18, 00:00:48, Serial0/0/1
O 10.89.1.112/28 [110/101] via 172.16.0.2, 00:00:48, Serial0/0/0
O 10.89.2.96/28 [110/101] via 172.16.0.18, 00:00:49, Serial0/0/1
O 10.89.1.96/28 [110/101] via 172.16.0.2, 00:00:49, Serial0/0/0
O 10.89.2.16/28 [110/101] via 172.16.0.18, 00:00:49, Serial0/0/1
O 10.89.1.16/28 [110/101] via 172.16.0.2, 00:00:49, Serial0/0/0
D 10.93.2.16/28 [90/2304000] via 172.16.0.18, 00:00:49, Serial0/0/1
D 10.93.1.16/28 [90/2304000] via 172.16.0.2, 00:00:49, Serial0/0/0
O 10.95.2.7/32 [110/101] via 172.16.0.18, 00:00:49, Serial0/0/1
O 10.95.1.4/32 [110/101] via 172.16.0.2, 00:00:49, Serial0/0/0
O 10.89.2.0/28 [110/101] via 172.16.0.18, 00:00:49, Serial0/0/1
O 10.95.2.6/32 [110/101] via 172.16.0.18, 00:00:49, Serial0/0/1
O 10.95.1.5/32 [110/101] via 172.16.0.2, 00:00:49, Serial0/0/0
O 10.89.1.0/28 [110/101] via 172.16.0.2, 00:00:50, Serial0/0/0
C 10.89.0.0/28 is directly connected, FastEthernet0/1.801
D 10.95.2.3/32 [90/1920000] via 172.16.0.18, 00:00:50, Serial0/0/1
C 10.95.0.1/32 is directly connected, Loopback0
D 10.93.2.0/28 [90/2304000] via 172.16.0.18, 00:00:50, Serial0/0/1
D 10.95.1.2/32 [90/1920000] via 172.16.0.2, 00:00:50, Serial0/0/0
D 10.93.1.0/28 [90/2304000] via 172.16.0.2, 00:00:50, Serial0/0/0
O 10.89.2.48/28 [110/101] via 172.16.0.18, 00:00:50, Serial0/0/1
O 10.89.1.48/28 [110/101] via 172.16.0.2, 00:00:51, Serial0/0/0
O 10.89.2.32/28 [110/101] via 172.16.0.18, 00:00:51, Serial0/0/1
O 10.89.1.32/28 [110/101] via 172.16.0.2, 00:00:51, Serial0/0/0
O 10.93.2.32/28 [110/101] via 172.16.0.18, 00:00:51, Serial0/0/1
O 10.93.1.32/28 [110/101] via 172.16.0.2, 00:00:51, Serial0/0/0
126
Почему в таблице маршрутизации пропали все маршруты протокола RIP,
а вместо них появились маршруты протокола OSPF? Почему маршруты
протокола EIGRP не указывают дальше одного перехода?
Шаг 4
Посмотрите таблицу топологии протокола EIGRP.
r1#show ip eigrp topology
IP-EIGRP Topology Table for AS(200)/ID(10.95.0.1)
Codes: P - Passive, A - Active, U - Update, Q - Query, R - Reply,
r - reply Status, s - sia Status
P 10.93.2.16/28, 1 successors, FD is 2304000
via 172.16.0.18 (2304000/1792000), Serial0/0/1
P 10.93.1.16/28, 1 successors, FD is 2304000
via 172.16.0.2 (2304000/1792000), Serial0/0/0
P 10.89.0.0/28, 1 successors, FD is 28160
via Connected, FastEthernet0/1.801
P 10.95.2.3/32, 1 successors, FD is 1920000
via 172.16.0.18 (1920000/128256), Serial0/0/1
P 10.95.0.1/32, 1 successors, FD is 128256
via Connected, Loopback0
P 10.93.2.0/28, 1 successors, FD is 2304000
via 172.16.0.18 (2304000/1792000), Serial0/0/1
P 10.95.1.2/32, 1 successors, FD is 1920000
via 172.16.0.2 (1920000/128256), Serial0/0/0
P 10.93.1.0/28, 1 successors, FD is 2304000
via 172.16.0.2 (2304000/1792000), Serial0/0/0
P 172.16.0.16/28, 1 successors, FD is 1792000
via Connected, Serial0/0/1
P 172.16.0.0/28, 1 successors, FD is 1792000
via Connected, Serial0/0/0
Почему таблица топологии не содержит всей топологической
информации?
Шаг 5
Измените административное расстояние для протокола RIP на его
административное расстояние по умолчанию на всех остальных
маршрутизаторах стенда.
Шаг 6
Посмотрите таблицу топологии протокола EIGRP.
r1#show ip eigrp topology
IP-EIGRP Topology Table for AS(200)/ID(10.95.0.1)
Codes: P - Passive, A - Active, U - Update, Q - Query, R - Reply,
r - reply Status, s - sia Status
P 10.89.2.80/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.80/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.89.2.64/28, 1 successors, FD is 2432000
127
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.64/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.89.2.112/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.112/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.89.2.96/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.96/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.89.2.16/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.16/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.93.2.16/28, 1 successors, FD is 2304000
via 172.16.0.18 (2304000/1792000), Serial0/0/1
P 10.93.1.16/28, 1 successors, FD is 2304000
via 172.16.0.2 (2304000/1792000), Serial0/0/0
P 10.95.1.4/32, 1 successors, FD is 2432000
via 172.16.0.2 (2432000/1920000), Serial0/0/0
P 10.95.2.7/32, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.95.1.5/32, 1 successors, FD is 2432000
via 172.16.0.2 (2432000/1920000), Serial0/0/0
P 10.89.2.0/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.95.2.6/32, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.0/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.89.0.0/28, 1 successors, FD is 28160
via Connected, FastEthernet0/1.801
P 10.95.2.3/32, 1 successors, FD is 1920000
via 172.16.0.18 (1920000/128256), Serial0/0/1
P 10.95.0.1/32, 1 successors, FD is 128256
via Connected, Loopback0
P 10.93.2.0/28, 1 successors, FD is 2304000
via 172.16.0.18 (2304000/1792000), Serial0/0/1
P 10.95.1.2/32, 1 successors, FD is 1920000
via 172.16.0.2 (1920000/128256), Serial0/0/0
P 10.93.1.0/28, 1 successors, FD is 2304000
via 172.16.0.2 (2304000/1792000), Serial0/0/0
P 10.89.2.48/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.48/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.89.2.32/28, 1 successors, FD is 2432000
via 172.16.0.18 (2432000/1920000), Serial0/0/1
P 10.89.1.32/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 10.93.2.32/28, 1 successors, FD is 2306560
via 172.16.0.18 (2306560/1794560), Serial0/0/1
P 10.93.1.32/28, 1 successors, FD is 2306560
via 172.16.0.2 (2306560/1794560), Serial0/0/0
P 172.16.0.16/28, 1 successors, FD is 1792000
via Connected, Serial0/0/1
P 172.16.0.0/28, 1 successors, FD is 1792000
via Connected, Serial0/0/0
В таблице топологии присутствует полная топологическая информация.
128
Шаг 7
Посмотрите таблицу маршрутизации на маршрутизаторах стенда.
r1#show ip route
.. .. ..
172.16.0.0/28 is subnetted, 2 subnets
C 172.16.0.16 is directly connected, Serial0/0/1
C 172.16.0.0 is directly connected, Serial0/0/0
10.0.0.0/8 is variably subnetted, 30 subnets, 2 masks
D 10.89.2.80/28 [90/2432000] via 172.16.0.18, 00:01:11, Serial0/0/1
D 10.89.1.80/28 [90/2306560] via 172.16.0.2, 00:00:49, Serial0/0/0
D 10.89.2.64/28 [90/2432000] via 172.16.0.18, 00:01:13, Serial0/0/1
D 10.89.1.64/28 [90/2306560] via 172.16.0.2, 00:00:50, Serial0/0/0
D 10.89.2.112/28 [90/2432000] via 172.16.0.18, 00:01:13, Serial0/0/1
D 10.89.1.112/28 [90/2306560] via 172.16.0.2, 00:00:50, Serial0/0/0
D 10.89.2.96/28 [90/2432000] via 172.16.0.18, 00:01:13, Serial0/0/1
D 10.89.1.96/28 [90/2306560] via 172.16.0.2, 00:00:51, Serial0/0/0
D 10.89.2.16/28 [90/2432000] via 172.16.0.18, 00:01:13, Serial0/0/1
D 10.89.1.16/28 [90/2306560] via 172.16.0.2, 00:00:31, Serial0/0/0
D 10.93.2.16/28 [90/2304000] via 172.16.0.18, 00:01:49, Serial0/0/1
D 10.93.1.16/28 [90/2304000] via 172.16.0.2, 00:01:49, Serial0/0/0
D 10.95.2.7/32 [90/2432000] via 172.16.0.18, 00:01:13, Serial0/0/1
D 10.95.1.4/32 [90/2432000] via 172.16.0.2, 00:00:31, Serial0/0/0
D 10.95.2.6/32 [90/2432000] via 172.16.0.18, 00:01:13, Serial0/0/1
D 10.95.1.5/32 [90/2432000] via 172.16.0.2, 00:00:51, Serial0/0/0
D 10.89.2.0/28 [90/2432000] via 172.16.0.18, 00:01:14, Serial0/0/1
D 10.89.1.0/28 [90/2306560] via 172.16.0.2, 00:00:32, Serial0/0/0
C 10.89.0.0/28 is directly connected, FastEthernet0/1.801
D 10.95.2.3/32 [90/1920000] via 172.16.0.18, 00:01:50, Serial0/0/1
C 10.95.0.1/32 is directly connected, Loopback0
D 10.93.2.0/28 [90/2304000] via 172.16.0.18, 00:01:50, Serial0/0/1
D 10.95.1.2/32 [90/1920000] via 172.16.0.2, 00:01:50, Serial0/0/0
D 10.93.1.0/28 [90/2304000] via 172.16.0.2, 00:01:50, Serial0/0/0
D 10.89.2.48/28 [90/2432000] via 172.16.0.18, 00:01:14, Serial0/0/1
D 10.89.1.48/28 [90/2306560] via 172.16.0.2, 00:00:33, Serial0/0/0
D 10.89.2.32/28 [90/2432000] via 172.16.0.18, 00:01:16, Serial0/0/1
D 10.89.1.32/28 [90/2306560] via 172.16.0.2, 00:00:33, Serial0/0/0
D 10.93.2.32/28 [90/2306560] via 172.16.0.18, 00:01:16, Serial0/0/1
D 10.93.1.32/28 [90/2306560] via 172.16.0.2, 00:00:33, Serial0/0/0
Задание 3. Переход с протокола маршрутизации EIGRP на протокол
OSPF.
В этом задании необходимо перейти с маршрутизации по протоколу
EIGRP на маршрутизацию по протоколу OSPF.
Шаг 1
На маршрутизаторе R1 измените административное расстояние для
протокола OSPF на административное расстояние равное 80.
Шаг 2
Убедитесь, что административное расстояние сменялось.
129
r2#show ip protocols ospf
Routing Protocol is "ospf 1"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
Router ID 2.2.2.2
Number of areas in this router is 1. 1 normal 0 stub 0 nssa
Maximum path: 4
Routing for Networks:
10.93.1.0 0.0.0.31 area 1
10.95.1.2 0.0.0.0 area 1
172.16.0.0 0.0.0.15 area 1
172.16.0.32 0.0.0.15 area 1
Reference bandwidth unit is 100 mbps
Passive Interface(s):
FastEthernet0/0
FastEthernet0/1
Serial0/1/1
Loopback0
Passive Interface(s):
VoIP-Null0
Routing Information Sources:
Gateway Distance Last Update
3.3.3.3 80 00:14:56
6.6.6.6 80 00:13:34
4.4.4.4 80 00:13:59
1.1.1.1 80 00:21:43
7.7.7.7 80 00:13:34
5.5.5.5 80 00:13:59
Distance: (default is 80)
Шаг 3
Посмотрите таблицу маршрутизации маршрутизатора R1.
r1#show ip route
.. .. ..
172.16.0.0/28 is subnetted, 2 subnets
C 172.16.0.16 is directly connected, Serial0/0/1
C 172.16.0.0 is directly connected, Serial0/0/0
10.0.0.0/8 is variably subnetted, 30 subnets, 2 masks
O 10.89.2.80/28 [80/101] via 172.16.0.18, 00:00:07, Serial0/0/1
O 10.89.1.80/28 [80/101] via 172.16.0.2, 00:00:07, Serial0/0/0
O 10.89.2.64/28 [80/101] via 172.16.0.18, 00:00:07, Serial0/0/1
O 10.89.1.64/28 [80/101] via 172.16.0.2, 00:00:08, Serial0/0/0
O 10.89.2.112/28 [80/101] via 172.16.0.18, 00:00:08, Serial0/0/1
O 10.89.1.112/28 [80/101] via 172.16.0.2, 00:00:08, Serial0/0/0
O 10.89.2.96/28 [80/101] via 172.16.0.18, 00:00:09, Serial0/0/1
O 10.89.1.96/28 [80/101] via 172.16.0.2, 00:00:09, Serial0/0/0
O 10.89.2.16/28 [80/101] via 172.16.0.18, 00:00:09, Serial0/0/1
O 10.89.1.16/28 [80/101] via 172.16.0.2, 00:00:09, Serial0/0/0
O 10.93.2.16/28 [80/100] via 172.16.0.18, 00:00:09, Serial0/0/1
O 10.93.1.16/28 [80/100] via 172.16.0.2, 00:00:09, Serial0/0/0
O 10.95.2.7/32 [80/101] via 172.16.0.18, 00:00:09, Serial0/0/1
O 10.95.1.4/32 [80/101] via 172.16.0.2, 00:00:09, Serial0/0/0
O 10.89.2.0/28 [80/101] via 172.16.0.18, 00:00:09, Serial0/0/1
O 10.95.2.6/32 [80/101] via 172.16.0.18, 00:00:09, Serial0/0/1
O 10.95.1.5/32 [80/101] via 172.16.0.2, 00:00:09, Serial0/0/0
O 10.89.1.0/28 [80/101] via 172.16.0.2, 00:00:10, Serial0/0/0
C 10.89.0.0/28 is directly connected, FastEthernet0/1.801
O 10.95.2.3/32 [80/51] via 172.16.0.18, 00:00:10, Serial0/0/1
C 10.95.0.1/32 is directly connected, Loopback0
O 10.93.2.0/28 [80/100] via 172.16.0.18, 00:00:10, Serial0/0/1
130
