698

Chapter 26 Design-for-Testability Patterns

the transaction. As a consequence, we can exercise the logic, verify the outcome, and

then abort the transaction, leaving no trace of our activity in the database.

To implement Humble Transaction Controller, we use an Extract Method

[Fowler] refactoring to move all the logic we want to test out of the code that

controls the transaction and into a separate method that knows nothing about

transaction control and that can be called by the test. Because the caller con-

trols the transaction, the test can start, commit (if it so chooses), and (most

commonly) roll back the transaction. In this case, the behavior—not the

dependencies—causes us to bypass the Humble Object when we are testing

the business logic. As a result, we are more likely to be able to get away with a

Poor Man’s Humble Object.

As for the Humble Object, it contains no business logic. Thus the only behavior

that needs to be tested is whether the Humble Object commits and rolls back the

transaction properly based on the outcome of the methods it calls. We can write a

test that replaces the testable component with a Test Stub (page 529) that throws

an exception and then verify that this activity results in a rollback of the transac-

tion. If we are using a Poor Man’s Humble Object, the stub would be implemented

as a Subclassed Test Double (see Test-Speciﬁ c Subclass on page 579) that overrides

the “real” methods with methods that throw exceptions.

Many of the major application server technologies support this pattern either

directly or indirectly by taking transaction control away from the business objects

that we write. If we are building our software without using a transaction control

framework, we may need to implement our own Humble Transaction Controller.

See the “Implementation Notes” section for some ideas on how we can enforce

the separation.

Variation: Humble Container Adapter

Speaking of “containers,” we often have to implement speciﬁ c interfaces to

allow our objects to run inside an application server (e.g., the “EJB session

bean” interface). Another variation on the Humble Object pattern is to design

our objects to be container-independent and then have a Humble Container

Adapter adapt them to the interface required by container. This strategy makes

our logic components easy to test outside the container, which dramatically

reduces the time required for an “edit–compile–test” cycle.

Implementation Notes

We can make the logic that normally runs inside the Humble Object testable in

several different ways. All of these techniques share one commonality: They in-

volve exposing the logic so that it can be veriﬁ ed using synchronous tests. They

Humble

Object

699

vary, however, in terms of how the logic is exposed. Regardless of how logic ex-

posure occurs, test-driven purists would prefer that tests verify that the Humble

Object is calling the extracted logic properly. This can be done by replacing the

real logic methods with some kind of Test Double (page 522) implementation.

Variation: Poor Man’s Humble Object

The simplest way to isolate and expose each piece of logic we want to verify is

to place it into a separate method. We can do so by using an Extract Method

refactoring on in-line logic and then making the resulting method visible from

the test. Of course, this method cannot require anything from the context. Ideally

everything the method needs to do its work will be passed in as arguments but this

information could also be placed in ﬁ elds. Problems may arise if the testable com-

ponent needs to call methods to access information it needs and those methods

are dependent on the (nonexistent/faked) context, as this dependency makes

writing the tests more complex.

This approach, which constitutes the “poor man’s” Humble Object, works well

if no obstacles prevent the instantiation of the Humble Object (e.g., automatically

starting its thread, no public constructor, unsatisﬁ able dependencies). Use of a Test-

Speciﬁ c Subclass can also help break these dependencies by providing a test-friendly

constructor and exposing private methods to the test.

When testing a Subclassed Humble Object or a Poor Man’s Humble Object,

we can build the Test Spy (page 538) as a Subclassed Test Double of the Humble

Object to record when the methods in question were called. We can then use

assertions within the Test Method (page 348) to verify that the values recorded

match the values expected.

Variation: True Humble Object

At the other extreme, we can put the logic we want to test into a separate class

and have the Humble Object delegate to an instance of it. This approach, which

was implied in the introduction to this pattern, will work in almost any circum-

stance where we have complete control over the code.

Sometimes the host framework requires that its objects hold certain responsi-

bilities that we cannot move elsewhere. For example, a GUI framework expects

its view objects to contain data for the controls of the GUI and the data that

those controls display on the screen. In these cases we must either give the test-

able object a reference to the Humble Object and have it manipulate the data for

that object or put some minimal update logic in the Humble Object and accept

that it won’t be covered by automated tests. The former approach is almost

always possible and is always preferable.

Humble Object

Humble

Object

700

Chapter 26 Design-for-Testability Patterns

To refactor to a True Humble Object, we normally do a series of Extract

Method refactorings to decouple the public interface of the Humble Object

from the implementation logic we plan to delegate. Then we do an Extract Class

[Fowler] refactoring to move all the methods—except the ones that deﬁ ne the

public interface of the Humble Object—to the new “testable” class. We introduce

an attribute (a ﬁ eld) to hold a reference to an instance of the new class and initial-

ize it to an instance of the new class either as part of the constructor or using

Lazy Initialization [SBPP] in each interface method.

When testing a True Humble Object (where the Humble Object delegates to a

separate class), we typically use a Lazy Mock Object (see Mock Object on page

544) or Test Spy to verify that the extracted class is called correctly. By contrast,

using the more common Active Mock Object (see Mock Object) is problematic

in this situation because the assertions are made on a different thread from the

Testcase Object (page 382) and failures won’t be detected unless we ﬁ nd a way

to channel them back to the test thread.

To ensure that the extracted testable component is instantiated properly, we

can use an observable Object Factory (see Dependency Lookup on page 686) to

construct the extracted component. The test can register as a listener to verify

the correct method is called on the factory. We can also use a regular factory

object and replace it during the test with a Mock Object or Test Stub to monitor

which factory method was called.

Variation: Subclassed Humble Object

In between the extremes of the Poor Man’s Humble Object and the True Humble

Object are approaches that involve clever use of subclassing to put the logic into

separate classes while still allowing them to be on a single object. A number of

different ways to do this are possible, depending on whether the Humble Object

class needs to subclass a speciﬁ c framework class. I won’t go into a lot of detail

here as this technique is very speciﬁ c to the language and runtime environment.

Nevertheless, you should recognize that the basic options are either having the

framework-dependent class inherit the logic to be tested from a superclass

or having the class delegate to an abstract method that is implemented by a

subclass.

Motivating Example (Humble Executable)

In this example, we are testing some logic that runs in its own thread and

processes each request as it arrives. In each test, we start up the thread, send

it some messages, and wait long enough so that our assertions pass. Unfortu-

nately, it takes several seconds for the thread to start up, become initialized,

Humble

Object

701

and process the ﬁ rst request. Thus the test fails sporadically unless we include

a two-second delay after starting the thread.

public class RequestHandlerThreadTest extends TestCase {

private static ﬁnal int TWO_SECONDS = 3000;

public void testWasInitialized_Async()

throws InterruptedException {

// Setup

RequestHandlerThread sut = new RequestHandlerThread();

// Exercise

sut.start();

// Verify

Thread.sleep(TWO_SECONDS);

assertTrue(sut.initializedSuccessfully());

}

public void testHandleOneRequest_Async()

throws InterruptedException {

// Setup

RequestHandlerThread sut = new RequestHandlerThread();

sut.start();

// Exercise

enqueRequest(makeSimpleRequest());

// Verify

Thread.sleep(TWO_SECONDS);

assertEquals(1, sut.getNumberOfRequestsCompleted());

assertResponseEquals(makeSimpleResponse(), getResponse());

}

Ideally, we would like to test the thread with each kind of transaction individu-

ally to achieve better Defect Localization (see page 22). Unfortunately, if we did

so our test suite would take many minutes to run because each test includes a

delay of several seconds. Another problem is that the tests won’t result in an error

if our active object has an exception in its own thread.

A two-second delay may not seem like a big deal, but consider what happens

when we have a dozen such tests. It would take us almost half a minute to run

these tests. Contrast this performance with that of normal tests—we can run

several hundred of those tests each second. Testing via the executable is affecting

our productivity negatively. For the record, here’s the code for the executable:

public class RequestHandlerThread extends Thread {

private boolean _initializationCompleted = false;

private int _numberOfRequests = 0;

public void run() {

initializeThread();

processRequestsForever();

}

Humble Object

Humble

Object

702

Chapter 26 Design-for-Testability Patterns

public boolean initializedSuccessfully() {

return _initializationCompleted;

}

void processRequestsForever() {

Request request = nextMessage();

do {

Response response = processOneRequest(request);

if (response != null) {

putMsgOntoOutputQueue(response);

}

request = nextMessage();

} while (request != null);

}

To avoid the distraction of the business logic, I have already used an Extract

Method refactoring to move the real logic into the method processOneRequest.

Likewise, the actual initialization logic is not shown here; sufﬁ ce it to say that

this logic sets the variable _initializationCompleted when it ﬁ nishes successfully.

Refactoring Notes

To create a Poor Man’s Humble Object, we expose the methods to make them

visible from the test. (If the code used in-line logic, we would do an Extract

Method refactoring ﬁ rst.) If there were any dependencies on the context, we

would need to do an Introduce Parameter [JBrains] refactoring or an Introduce

Field [JetBrains] refactoring so that the processOneRequest method need not access

anything from the context.

To create a true Humble Object, we can do an Extract Class refactoring on the

executable to create the testable component, leaving behind just the Humble Object

as an empty shell. This step typically involves doing the Extract Method refactoring

described above to separate the logic we want to test (e.g., the initializeThread

method and the processOneRequest method) from the logic that interacts with the

context of the executable. We then do an Extract Class refactoring to introduce the

testable component class (essentially a single Strategy [GOF] object) and move all

methods except the public interface methods over to it. The Extract Class refac-

toring includes introducing a ﬁ eld to hold a reference to the new object and creating

an instance. It also includes ﬁ xing all of the public methods so that they call the

methods that were moved to the new testable class.

Humble

Object

703

Example: Poor Man’s Humble Executable

Here is the same set of tests rewritten as a Poor Man’s Humble Object:

public void testWasInitialized_Sync()

throws InterruptedException {

// Setup

RequestHandlerThread sut = new RequestHandlerThread();

// Exercise

sut.initializeThread();

// Verify

assertTrue(sut.initializedSuccessfully());

}

public void testHandleOneRequest_Sync()

throws InterruptedException {

// Setup

RequestHandlerThread sut = new RequestHandlerThread();

// Exercise

Response response = sut.processOneRequest(makeSimpleRequest());

// Verify

assertEquals(1, sut.getNumberOfRequestsCompleted());

assertResponseEquals(makeSimpleResponse(), response);

}

Here, we have made the methods initializeThread and processOneRequest public so

that we can call them synchronously from the test. Note the absence of a delay in

this test. This approach works well as long as we can instantiate the executable

component easily.

Example: True Humble Executable

Here is the code for our SUT refactored to use a True Humble Executable:

public class HumbleRequestHandlerThread extends Thread

implements Runnable {

public RequestHandler requestHandler;

public HumbleRequestHandlerThread() {

super();

requestHandler = new RequestHandlerImpl();

}

public void run() {

requestHandler.initializeThread();

processRequestsForever();

}

public boolean initializedSuccessfully() {

Humble Object

Humble

Object

704

Chapter 26 Design-for-Testability Patterns

return requestHandler.initializedSuccessfully();

}

public void processRequestsForever() {

Request request = nextMessage();

do {

Response response =

requestHandler.processOneRequest(request);

if (response != null) {

putMsgOntoOutputQueue(response);

}

request = nextMessage();

} while (request != null);

}

Here, we have moved the method processOneRequest to a separate class that we

can instantiate easily. Below is the same test rewritten to take advantage of the

extracted component. Note the absence of a delay in this test.

public void testNotInitialized_Sync()

throws InterruptedException {

// Setup/Exercise

RequestHandler sut = new RequestHandlerImpl();

// Verify

assertFalse("init", sut.initializedSuccessfully());

}

public void testWasInitialized_Sync()

throws InterruptedException {

// Setup

RequestHandler sut = new RequestHandlerImpl();

// Exercise

sut.initializeThread();

// Verify

assertTrue("init", sut.initializedSuccessfully());

}

public void testHandleOneRequest_Sync()

throws InterruptedException {

// Setup

RequestHandler sut = new RequestHandlerImpl();

// Exercise

Response response = sut.processOneRequest( makeSimpleRequest() );

// Verify

assertEquals( 1, sut.getNumberOfRequestsDone());

assertResponseEquals( makeSimpleResponse(), response);

}

Because we have introduced delegation to another object, we should probably

verify that the delegation occurs properly. The next test veriﬁ es that the Humble

Humble

Object

705

Object calls the initializeThread method and the processOneRequest method on the

newly created testable component:

public void testLogicCalled_Sync()

throws InterruptedException {

// Setup

RequestHandlerRecordingStub mockHandler =

new RequestHandlerRecordingStub();

HumbleRequestHandlerThread sut = new HumbleRequestHandlerThread();

// Mock Installation

sut.setHandler( mockHandler );

sut.start();

// Exercise

enqueRequest(makeSimpleRequest());

// Verify

Thread.sleep(TWO_SECONDS);

assertTrue("init", mockHandler.initializedSuccessfully() );

assertEquals( 1, mockHandler.getNumberOfRequestsDone() );

}

Note that this test does require at least a small delay to allow the thread to

start up. The delay is shorter, however, because we have replaced the real logic

component with a Test Double that responds instantly and only one test now

requires the delay. We could even move this test to a separate test suite that is

run less frequently (e.g., only during the automated build process) to ensure that

all tests performed before each check-in run quickly.

The other signiﬁ cant thing to note is that we are using a Test Spy rather

than a Mock Object. Because the assertions done by the Mock Object would be

raised in a different thread from the Test Method, the Test Automation Frame-

work (page 298)—in this example, JUnit—won’t catch them. As a consequence,

the test might indicate “pass” even though assertions in the Mock Object are

failing. By making the assertions in the Test Method, we avoid having to do

something special to relay the exceptions thrown by the Mock Object back to

the thread in which the Test Method is executing.

The preceding test veriﬁ ed that our Humble Object actually delegates to

the Test Spy that we have installed. It would also be a good idea to verify that

our Humble Object actually initializes the variable holding the delegate to the

appropriate class. Here’s a simple way to do so:

public void testConstructor() {

// Exercise

HumbleRequestHandlerThread sut = new HumbleRequestHandlerThread();

// Verify

String actualDelegateClass = sut.requestHandler.getClass().getName();

assertEquals( RequestHandlerImpl.class.getName(),

actualDelegateClass);

}

Humble Object

Humble

Object

706

Chapter 26 Design-for-Testability Patterns

This Constructor Test (see Test Method) veriﬁ es that a speciﬁ c attribute has been

initialized.

Example: Humble Dialog

Many development environments let us build the user interface visually by

dragging and dropping various objects (“widgets”) onto a canvas. They let us

add behavior to these visual objects by selecting one of several possible actions

or events speciﬁ c to that visual object and typing logic into the code window

presented by the IDE. This logic may involve invoking the application behind

the user interface or it may involve modifying the state of this or some other

visual object.

Visual objects are very difﬁ cult to test efﬁ ciently because they are tightly

coupled to the presentation framework that invokes them. To provide the

visual object with all the information and facilities it requires, the test would

need to simulate that environment—quite a challenge. This makes testing very

complicated, so much so that many development teams don’t bother testing

the presentation logic at all. This lack of testing, not surprisingly, often leads to

Production Bugs caused by untested code and Untested Requirements.

To create the Humble Dialog, we extract all the logic from the view com-

ponent into a nonvisual component that is testable via synchronous tests. If

this component needs to update the view object’s (Humble Dialog’s) state, the

Humble Dialog is passed in as an argument. When testing the nonvisual com-

ponent, we typically replace the Humble Dialog with a Mock Object that is

conﬁ gured with the indirect input values and the expected behavior (indirect

outputs). In GUI frameworks that require the Humble Dialog to register itself

with the framework for each event it wishes to see, the nonvisual component can

unmanageable dependencies on the context). This ﬂ exibility makes the Humble

Dialog

even simpler because the events go directly to the nonvisual component

and require no delegation logic.

The following code sample is taken from a VB view component (.ctl) that

includes some nontrivial logic. It is part of a custom plug-in we built for Mercury

Interactive’s TestDirector tool.

' Interface method, TestDirector will call this method

' to display the results.

Public Sub ShowResultEx(TestSetKey As TdTestSetKey, _

TSTestKey As TdTestKey, _

ResultKey As TdResultKey)

Humble

Object

707

Dim RpbFiles As OcsRpbFiles

Set RpbFiles = getTestResultFileNames(ResultKey)

ResultsFileName = RpbFiles.ActualResultFileName

ShowFileInBrowser ResultsFileName

End Sub

Function getTestResultFileNames(ResultKey As Variant) As OcsRpbFiles

On Error GoTo Error

Dim Attachments As Collection

Dim thisTest As Run

Dim RpbFiles As New OcsRpbFiles

Call EnsureConnectedToTd

Set Attachments = testManager.GetAllAttachmentsOfRunTest(ResultKey)

Call RpbFiles.LoadFromCollection(Attachments, "RunTest")

Set getTestResultFileNames = RpbFiles

Exit Function

Error:

' do something ...

End Function

Ideally, we would like to test the logic. Unfortunately, we cannot construct the

objects passed in as parameters because they don’t have public constructors.

Passing in objects of some other type isn’t possible either, because the types of

the function parameters are hard-coded to be speciﬁ c concrete classes.

We can do an Extract Testable Component (page 735) refactoring on the ex-

ecutable to create the testable component, leaving behind just the Humble Dialog

as an empty shell. This approach typically involves doing several Extract Method

refactorings (already done in the original example to make the refactoring easier

to understand), one for each chunk of logic that we want to move. We then do

an Extract Class refactoring to create our new testable component class. The

Extract Class refactoring may include both Move Method [Fowler] and Move

Field [Fowler] refactorings to move the logic and the data it requires out of the

Humble Dialog and into the new testable component.

Here’s the same view converted to a Humble Dialog:

' Interface method, TestDirector will call this method

' to display the results.

Public Sub ShowResultEx(TestSetKey As TdTestSetKey, _

TSTestKey As TdTestKey, _

ResultKey As TdResultKey)

Dim RpbFiles As OcsRpbFiles

Call EnsureImplExists

Set RpbFiles = Implementation.getTestResultFileNames(ResultKey)

Humble

Object

Humble Object
