Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
AXC_OnBtnComment
Function
External message window operation
This function displays the comment of the previously selected messages.
Syntax
BOOL AXC_OnBtnComment (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
System Manual, 11/2008,
861
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
AXC_OnBtnEmergAckn
Function
External message window operation
This function opens the acknowledgement dialog (emergency acknowledgement/reset).
Syntax
BOOL AXC_OnBtnEmergAckn(char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
862
System Manual, 11/2008,
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
AXC_OnBtnHideDlg
Function
This function opens the display options dialog for defining the messages that are to be
displayed in the message window. The options are "All messages", "Shown messages" or
"Hidden messages".
Syntax
BOOL AXC_OnBtnHideDlg(char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
System Manual, 11/2008,
863
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
AXC_OnBtnHideUnhideMsg
Function
The function hides the selected message or displays again the hidden message.
Syntax
BOOL AXC_OnBtnHideUnhideMsg(char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
864
System Manual, 11/2008,
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
AXC_OnBtnHit
Function
This function displays the messages stored in the hit list in a message window.
Syntax
BOOL AXC_OnBtnHit (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
System Manual, 11/2008,
865
See also
AXC_OnBtnMsgFirst example (Page 1471)
AXC_OnBtnHornAckn
Function
External message window operation
This function acknowledges the horn signal.
Syntax
BOOL AXC_OnBtnHornAckn (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
866
System Manual, 11/2008,
AXC_OnBtnInfo
Function
External message window operation
This function displays the information text.
Syntax
BOOL AXC_OnBtnInfo (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
System Manual, 11/2008,
867
AXC_OnBtnLock
Function
External message window operation
This function opens the "Set the Lock List Parameters" dialog.
Syntax
BOOL AXC_OnBtnLock (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
868
System Manual, 11/2008,
AXC_OnBtnLockUnlock
Function
This function locks the selected message in the message window. This message will then no
longer be archived.
This function unlocks the selected message in the lock list.
Syntax
BOOL AXC_OnBtnLockUnlock (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
System Manual, 11/2008,
869
AXC_OnBtnLockWin
Function
External message window operation.
This function calls the lock list.
Syntax
BOOL AXC_OnBtnLockWin (char* lpszPictureName, char* lpszObjectName)
Parameters
lpszPictureName
Pointer to the name of the picture in which the WinCC Alarm Control is located
lpszObjectName
Pointer to the object name of the WinCC Alarm Control
Return value
TRUE
The function has been completed without any errors.
FALSE
An error has occurred.
Note
The standard function is no longer supported for the new WinCC AlarmControl as of WinCC
V7.0.
See also
AXC_OnBtnMsgFirst example (Page 1471)
ANSI-C function descriptions
3.2 Standard functions
MDM - WinCC: Scripting (VBS, ANSI-C, VBA)
870
System Manual, 11/2008,
