PLANNING, DESIGNING, AND CONSTRUCTING TENSION LEG PLATFORMS 111

9.2.5.2 Analysis Methods

Methods for estimating fatigue life are covered in 9.6 for each major tendon component.

9.2.5.3 Environmental Conditions

Tendon fatigue analysis is generally conducted by calculating cumulative fatigue damage over all anticipated

sea states over the design service life. A scatter diagram of anticipated environments with associated

probabilities is typically used.

Care should be taken to appropriately consider unique metocean situations such as sustained currents that

may induce VIV of tendons over a sustained period of time, and cyclonic storms that may produce sustained

exposure—i.e. where sufficient data is available, hurricanes/typhoons should be directly included in the wave

scatter diagram used in fatigue analysis.

9.2.5.4 Single Event Fatigue

In addition to the conventional scatter diagram fatigue life calculation, the tendon components should

demonstrate robustness against low-cycle/high-stress fatigue due to more prolonged events that exceed the

probabilistic predictions. The intent is to screen for components that may incur excessive fatigue damage in

large sea states to the extent that a reasonable exceedence of the scatter diagram predictions can lead to

catastrophic failure.

In order to insure a reasonable level of robustness in this regard, tendon fatigue damage should be assessed

for all components over the duration of a single event based on the 100-year extreme storm, including the

ramp-up and ramp down before and after the storm. The duration to consider is to be determined by the

designer based on the data available and the response characteristics of the components. The unfactored

damage accumulated during this event should be equal to or less than 0.01.

Other 100-year return period events that may induce substantial tendon fatigue, such as loop currents in the

Gulf of Mexico, should also be considered in the same manner.

Damage calculated for single event fatigue should not be added to the damage predicted in the scatter

diagram fatigue analysis, nor compared to the associated safety factors. It is intended only as a robustness

check. See C.1 for more discussion.

9.2.6 Robustness of Design

Section 5.2.4 describes Safety Category S for survival conditions. Table 1 describes the load cases to which

this category should be applied. Section 9.6 gives specific criteria for this safety category with respect to

different tendon components.

Meeting these criteria will in principle insure a robust design for components that have nonbrittle failure

modes. Material selection and fabrication procedures described in this RP are intended to insure ductile

behavior of structural components. For example, tendon pipe should have a very ductile failure mode. So

overloading the tendon to or beyond storms associated with Safety Category S should not lead to

catastrophic failure.

Some mechanical components can have unusual failure modes for which, going beyond a certain load may

cause movement of mechanical pieces, and/or complete or partial disengagement of the component. Care

should be taken to prevent such failure modes from occurring in Safety Category S conditions.

An important example of such a component for a TLP is a typical tendon bottom connector, which is designed

to connect or disconnect by stroking the tendon downwards beyond the in-service load shoulder. The design

should be such that the connector does not disconnect in Safety Category S conditions (see 7.8.16). All

components in the tendon string should be examined for robustness of design, with particular attention paid to

any interactions. For example, a mechanical latch on the bottom connector to prevent stroke-out could be
