448 Part C Materials Properties Measurement

7.187 J.E. Field, R.H. Telling: The Young Modulus and

Poisson Ratio of Diamond (PCS Cavendish Lab., Cam-

bridge 1999)

7.188 C. Heermant, D. Dengel: Zur Abschätzung ‘klas-

sischer’ Werkstoffkennwerte mittels Universal-

härteprüfung, Z. Materialprüf. 38, 374–378 (1996),

(in German)

7.189 H.-H. Behncke: Bestimmung der Universalhärte und

anderer Kennwerte an dünnen Schichten, insbeson-

dere Hartstoffschichten, Härt.-Tech. Mitt. HTM 48,

3–10 (1993), (in German)

7.190 P. Grau, C. Ullner, H.-H. Behncke: Uncertainty of

depth sensing hardness, Z. Materialprüf. 39,362–

367 (1997)

7.191 M.F. Doerner, W.D. Nix: A method for interpreting

the data from depth sensing indentation instru-

ments, J. Mater. Res. 1, 601–609 (1986)

7.192 M. Petzold, C. Hagendorf, M. Füting, J.M. Olaf: Scan-

ning force microscopy of indenter tips and hardness

indentations, VDI Ber. 1194, 79 (1995)

7.193 C. Trindade, A. Cavaleiro, J.V. Fernandes: Estimation

of Young’s modulus and of hardness by ultra-low

load hardness tests with a Vickers indenter, ASTM

J. Test. Eval. 22, 365–369 (1994)

7.194 K. Hermann, N.M. Jennett, W. Wegener, J. Meneve,

K. Hasche, R. Seemann: Progress in determination

of the area function of indenters used for nanoin-

dentation, Thin Solid Films 377/378, 394–400 (2000)

7.195 R.B. King: Elastic analysis of some punch problems

for a layered medium, Int. J. Solids Struct. 23,1657–

1664 (1987)

7.196 A. Wehrstedt, C. Ullner: Standardization of the

instrumented indentation test – Historical devel-

opment and comments, Z. Materialprüf. 46, 106–112

(2004)

7.197 A. Bolshakov, G.M. Pharr: Inﬂuences of pile-up and

the measurement of mechanical properties by load

and depth sensing indentation techniques, J. Mater.

Res. 13, 1049–1058 (1998)

7.198 N.J. McCormick, M.G. Gee, D.J. Hall: The calibration

of the nanoindenter, Mater. Res. Soc. Symp. Proc.

308, 195–200 (1993)

7.199 T. Chudoba, F. Richter: Investigation of creep be-

haviour under load during indentation experiments

and its inﬂuence on hardness and modulus results,

Surf. Coat. Technol. 148(2/3), 191–198 (2001)

7.200 N. Schwarzer, F. Richter, G. Hecht: Elastic ﬁeld in

a coated half space under Hertzian pressure distri-

bution, Surf. Coat. Technol. 114, 292 (1999)

7.201 ISO 4516: Metallic and Other Inorganic Coatings –

Vickers and Knoop Microhardness Tests (Interna-

tional Standardization Organisation, Geneva 2002)

7.202 ASTM D-1474: Indentation Hardness of Organic Coat-

ings (ASTM Int., West Conshohocken 2003)

7.203

W.C. Oliver, G.M. Pharr: An improved technique for

determining hardness and elastic modulus using

load and displacement sensing indentation experi-

ments, J. Mater. Res. 7(6), 1564–1583 (1992)

7.204 ISO 14577-2: Metallic Materials – Instrumented

Indentation Test for Hardness and Materials Pa-

rameters – Part 2: Vericﬁcation and Calibration

of Testing Machines (International Organisation for

Standardization, Geneva 2002)

7.205 ISO 14577-3: Metallic Materials – Instrumented

Indentation Test for Hardness and Materials Pa-

rameters – Part 3: Calibration of Reference Blocks

(International Organisation for Standardization,

Geneva 2002)

7.206 Y. Tomota: Ferrum 4, 536–542 (1999), (in Japanese)

7.207 P.W. Bridgeman: Studies in Large Plastic Flow and

Fracture (Harvard Univ. Press, London 1964)

7.208 D. Tabor: The Hardness of Metals (Clarendon, Oxford

1951)

7.209 T. Yoshizawa: Hardness Test and Application (Shok-

abo, Tokyo 1967), (in Japanese)

7.210 K. Hirukawa, S. Matuoka, Y. Furuya, K. Miya-

hara: Nano-scaled strength analysis of a tempered

martensite, Trans. Jpn. Soc. Mech. Eng. A 68,1473–

1478 (2002)

7.211 G.I. Taylor, H. Quinney: The plastic deformation of

metals, Philos. Trans. R. Soc. A 230,323–362(1931)

7.212 Y. Murakami: Strength of Materials (Morikita Syup-

pan, Tokyo 1994)

7.213 C.-H. Park: Effect of solution hardening on high

speed deformation for ferritic steels, Z. Metallkd.

94, 53–59 (2003)

7.214 Y. Tomota: Deformation and Fracture at High Strain

Rates for Aluminum Alloys, Seminar Textbook (Inst.

Light Metals, Toyohashi 2003), (in Japanese)

7.215 T. Abe, Y. Furuya, S. Matuoka: 10

cycles fatigue

properties for a series of SUP 7 spring steels, Trans.

Jpn. Soc. Mech. Eng. A 696, 1050–1959 (2004)

7.216 F. Erdogan: Materials for Mechanical Engineering

(Soc. Mater. Sci. Jpn., Kyoto 1993)

7.217 P.C. Paris, F. Erdogan: A critical analysis of crack

propagation laws, Trans. ASME D 85, 528–534 (1963)

7.218 H.J. Frost, M.F. Ashby: Deformation Mechanism Map

(Pergamon, New York 1982)

7.219 Y. Tomota: Strength of steels at room tempera-

ture, Bull. Iron Steel Inst. Jpn. (Ferrum) 4,536–542

(1999)

7.220 J.E. Bailey, P.B. Hirsch: The dislocation distribu-

tion, ﬂow stress, and stored energy in cold-worked

polycrystalline silver, Philos. Mag. 4,85(1960)

7.221 W.C. Leslie: The Physical Metallurgy of Steels

(McGraw–Hill, New York 1985)

7.222 E.O. Hall: The deformation and aging of mild steel,

Proc. R. Soc. Lond. B 64,47–53(1951)

7.223 N.J. Petch: The cleavage strength of polycrystals,

J. Iron Steel Inst. 174,25–28(1953)

7.224 T. Fujita, Y. Yamada: SCC and HE of iron base

alloys. In: Stress Corrosion Cracking and Hydro-

gen Embrittlement of Iron Base Alloys NACE-5,

ed. by R.W. Staehle, J. Hochmann, R.D. McCright,

J.E. Slater (Nat. Assoc. Corrosion Engineers, Houston

1977) p. 736

Part C 7

Mechanical Properties References 449

7.225 JIS Standard: Testing Methods of Bonding Strength

of Adhesive (Japanese Standards Association, Tokyo

1999)

7.226 J. Onuki: Semiconductor Materials (Uchidaroho,

Tokyo 2004), (in Japanese)

7.227 Jpn. Soc. Composite Materials (Ed.): Handbook of

Composite Materials (Kohichido, Tokyo 1989)

7.228 H.M. Westergaard: Bearing pressures and cracks,

J. Appl. Mech. 6, 49–53 (1939)

7.229 G.R. Irwin: Analysis of stresses and strains near the

end of a crack traversing a plane, J. Appl. Mech. 24,

361–364 (1957)

7.230 M.L. Williams: On the stress distribution at the base

of a stationary crack, J. Appl. Mech. 24, 109–114 (1957)

7.231 ASTM E 399-90: Standard Test Method for Plane

Strain Fracture Toughness of Metallic Mater-

ials (American Society for Testing and Materials,

Philadelphia 1990)

7.232 J.R. Rice: A Path Independent Integral and the

Approximate Analysis of Strain Concentration by

Notches and Cracks, J. Appl. Mech. 35,379–386

(1968)

7.233 J.W. Hutchinson: Singular behavior at the end of

a tensile crack tip in a hardening material, J. Mech.

Phys. Solids 16, 13–31 (1968)

7.234 J.R. Rice, G.F. Rosengren: Plane strain deformation

near a crack tip in a power-law hardening material,

J. Mech. Phys. Solids 16,1–12(1968)

7.235 T.L. Anderson: Fracture Mechanics – Fundamen-

tals and Applications, 2nd edn. (CRC, Boca Raton

1995)

7.236 A.A. Wells: Application of fracture mechanics at and

beyond general yielding, Br. Weld. J. 10,563–570

(1963)

7.237 ASTM E 1820-99: Standard Test Method for Measure-

ment of Fracture Toughness (American Society for

Testing and Materials, Philadelphia 1990)

7.238 BS 7448-1997: Fracture Mechanics Test, Part I:

Method for Determination of K

, Critical CTOD and

Critical J Values of Metallic Materials (British Stan-

dard Institution, London 1997)

7.239 ISO 12737: Metallic Materials – Determination of

Plane-Strain Fracture Toughness (International Or-

ganization for Standardization, Geneva 1996)

7.240 ISO 12135: Metallic Materials – Uniﬁed Method of

Test for the Determination of Quasistatic Fracture

Toughness (International Organization for Stan-

dardization, Geneva 1996)

7.241 ASTM E 813-81: Standard Test Method for J

,AMea-

sure of Fracture Toughness (American Society for

Testing and Materials, Philadelphia 1981)

7.242 ASTM E 1152-87: Standard Test Method for Determin-

ing J–R Curves (American Society for Testing and

Materials, Philadelphia 1987)

7.243 ASTM E 1290-02: Standard Test Method for Crack-

Tip Opening Displacement (CTOD) Fracture Toughness

Measurement (American Society for Testing and Ma-

terials, Philadelphia 2002)

7.244 WES 1108-1995: Standard Test Method for Crack-

Tip Opening Displacement (CTOD) Fracture Toughness

Measurement (Japan Welding Engineering Society,

Tokyo 1995)

7.245 D.P. Fairchild: Fracture toughness testing of weld

heat-affected zones in structural steel, ASTM STP,

Vol. 1058 (American Society of Testing and Materials,

Philadelphia 1990) pp. 117–141

7.246 API RP 2Z: Recommended Practice for Preproduction

Qualiﬁcation for Steel Plates for Offshore Structures

(American Petroleum Institute, Washington 1998)

7.247 WES 1109-1995: Guidance for Crack-Tip Opening Dis-

placement (CTOD) Fracture Toughness Test Method of

Weld Heat-Affected Zone (Japan Welding Engineer-

ing Society, Tokyo 1995)

7.248 M.G. Dawes, H.G. Pisarski, S.J. Squirrell: Fracture

mechanics tests on welded joints, ASTM STP, Vol. 995

(American Society of Testing and Materials, Philadel-

phia 1989) pp. 191–213

7.249 P.C. Paris, M.P. Gomez, W.P. Anderson: A rational

analytic theory of fatigue, Trend Eng. 13,9–14(1961)

7.250 P.C. Paris, F. Erdogan: A critical analysis of crack

propagation laws, J. Basic Eng. 85,528–534(1960)

7.251 ASTM E 647-00: Standard Test Method for Mea-

surement of Fatigue Crack Growth Rates (American

Society of Testing and Materials, Philadelphia

2004)

7.252 C. Laird: The inﬂuence of metallurgical structure on

the mechanisms of fatigue crack propagation. In:

Fatigue Rack Propagation,ASTMSTP,Vol.415,ed.

by J. Grosskreutz (American Society of Testing and

Materials, Philadelphia 1967) pp. 131–167

7.253 R.W. Baker: Membrane Technology and Application,

2nd edn. (Wiley, New York 2004)

7.254 S.P. Nunes, K.-V. Peinemann: Membrane Technol-

ogy in the Chemical Industry (Wiley-VCH, New York

2001)

7.255 B.D. Freeman, I. Pinnau: Gas and liquid separa-

tions using membranes: An overview. In: Advanced

Materials for Membrane Separations, ACS Symp.,

Vol. 876, ed. by B.D. Freeman, I. Pinnau (American

Chemical Society, Washington 2004) pp. 1–23

7.256 K.Ghosal,R.T.Chern,B.D.Freeman,W.H.Daly,

I.I. Negulescu: Effect of basic substituents on gas

sorption and permeation in polysulfone, Macro-

molecules 29, 4360–4369 (1996)

7.257 S.N. Dhoot, B.D. Freeman, M.E. Stewart: Barrier

polymers. In: Encyclopedia of Polymer Science and

Technology, Vol. 5, ed. by J.I. Kroschwitz (Wiley In-

terscience, New York 2003) pp. 198–262

7.258 M. Mulder: Basic Principles of Membrane Technology

(Kluwer Academic, Dordrecht 1996)

7.259 W.S.W. Ho, K.K. Sirkar: Membrane Handbook (Chap-

man Hall, New York 1992)

7.260 J. Crank, G.S. Park: Diffusion in Polymers (Academic,

New York 1968)

7.261 J. Crank: The Mathematics of Diffusion, 2nd edn.

(Oxford Univ. Press, New York 1995)

Part C 7

450 Part C Materials Properties Measurement

7.262 W.J. Koros, G.K. Fleming: Membrane-based gas sep-

aration, J. Membr. Sci. 83, 1–80 (1993)

7.263 S.A. Stern: Polymers for gas separations: The next

decade, J. Membr. Sci. 94, 1–65 (1994)

7.264 K. Ghosal, B.D. Freeman: Gas separation using poly-

mer membranes: An overview, Polym. Adv. Technol.

5, 673–697 (1994)

7.265 R.M. Felder, G.S. Huvard: Permeation, diffusion and

sorption of gases and vapors. In: Methods of Exper-

imental Physics, Vol. 16C, ed. by R. Fava (Academic,

New York 1980) p. 315

7.266 W.J. Koros, C.M. Zimmerman: Transport and bar-

rier properties. In: Comprehensive Desk Reference

of Polymer Characterization and Analysis,ed.by

R.F. Brady (Oxford Univ. Press, Washington 2003)

7.267 B. Flaconneche, J. Martin, M.H. Klopffer: Transport

properties of gases in polymers: Experimental meth-

ods, Oil Gas Sci. Technol.-Rev. IFP 56, 245–259 (2001)

7.268 J. Crank, G.S. Park: Methods of measurement. In:

Diffusion in Polymers, ed. by J. Crank, G.S. Park

(Academic, New York 1968) pp. 1–39

7.269 T. Graham: On the absorption and dialytic sepa-

ration of gases by colloid septa part I: Action of

a septum of caoutchouc, Philos. Mag. 32,401–420

(1866)

7.270 R.B. Bird, W.E. Stewart, E.N. Lightfoot: Transport

Phenomena, 2nd edn. (Wiley, New York 2002)

7.271 R.R. Zolandz, G.K. Fleming: Gas permeation. In:

Membrane Handbook, ed. by W.S.W. Ho, K.K. Sirkar

(Chapman Hall, New York 1992) pp. 17–102

7.272 T.C. Merkel, V.I. Bondar, K. Nagai, B.D. Freeman,

I. Pinnau: Gas sorption, diffusion, and permeation

in poly(dimethylsiloxane), J. Polym. Sci. B 38,415–

434 (2000)

7.273 J.H. Petropoulos: Mechanisms and theories for

sorption and diffusion of gases in polymers.

In: Polymeric Gas Separation Membranes,ed.by

D.R. Paul, Y.P. Yampolskii (CRC, Boca Raton 1994)

7.274 B.D. Freeman: Mutual diffusion in polymeric sys-

tems. In: Comprehensive Polymer Science: First

Supplements, ed. by S.L. Aggarwal, S. Russo (Perga-

mon, New York 1992)

7.275 H. Lin, B.D. Freeman: Gas solubility, diffusivity and

permeability in poly(ethylene oxide), J. Membr. Sci.

239, 105–117 (2004)

7.276 W.J. Koros, D.R. Paul: CO

sorption in poly(ethylene

terephthalate) above and below the glass transition,

J. Polym. Sci. B 16,1947(1978)

7.277 E.L. Cussler: Facilitated and active transport. In:

Polymeric Gas Separation Membranes,ed.by

D.R. Paul, Y.P. Yampol’skii (CRC, Boca Raton 1994)

pp. 273–300

7.278 D.R. Paul, D.R. Kemp: The diffusion time lag in

polymer membranes containing adsorptive ﬁllers,

J. Polym. Sci. Symp. 41, 79–93 (1973)

7.279 W.J. Koros, D.R. Paul, A.A. Rocha: Carbon dioxide

sorption and transport in polycarbonate, J. Polym.

Sci. B 14,687–702(1976)

7.280 S.A. Stern, J.T. Mullhaupt, P.J. Gareis: The ef-

fect of pressure on the permeation of gases and

vapors through polyethylene. Usefulness of the cor-

responding states principle, AIChE Journal 15,64–73

(1969)

7.281 H.A. Daynes: The process of diffusion through

a rubber membrane, Proc. R. Soc. A 97,286–307

(1920)

7.282 R.M. Barrer: Permeation, diffusion and solution of

gases in organic polymers, Trans. Faraday Soc. 35,

628–643 (1939)

7.283 H.L. Frisch: The time lag in diffusion, J. Phys. Chem.

61, 93–95 (1957)

7.284 E.B. Mano, L.A. Durao: Review of laboratory methods

for the preparation of polymer ﬁlms, J. Chem. Educ.

50, 228–232 (1973)

7.285 J.M. Mohr, D.R. Paul: Effect of casting solvent on the

permeability of poly(4-methyl-1-pentene), Polymer

32, 1236–1243 (1991)

7.286 S.J. Metz: Water vapor and gas transport through

polymeric membranes. Ph.D. Thesis (University of

Twentie, Enschede 2003)

7.287 Z. Mogri, D.R. Paul: Membrane formation techniques

for gas permeation measurements for side-chain

crystalline polymers, J. Membr. Sci. 175,253–265

(2000)

7.288 T.T. Moore, S. Damle, P.J. Williams, W.J. Koros:

Characterization of low permeability gas separation

membranes and barrier materials; Design and op-

eration considerations, J. Membr. Sci. 245, 227–231

(2004)

7.289 T.C. Merkel, R.P. Gupta, B.S. Turk, B.D. Freeman:

Mixed-gas permeation of syngas components in

poly(dimethylsiloxane) and poly(1-trimethylsilyl-1-

propyne) at elevated temperatures, J. Membr. Sci.

191, 85–94 (2001)

7.290 D.G. Pye, H.H. Hoehn, M. Panar: Measurement of gas

permeability of polymers. I. Permeabilities in con-

stant volume/variable pressure apparatus, J. Appl.

Polym. Sci. 20, 1921–1931 (1976)

7.291 E.S. Burnett: Compressibility determinations with-

out volume measurements, J. Appl. Mech. 3,136–140

(1936)

7.292 H. Yasuda, K.J. Rosengren: Isobaric measurement of

gas permeability of polymers, J. Appl. Polym. Sci. 14,

2839–2877 (1970)

7.293 D.G. Pye, H.H. Hoehn, M. Panar: Measurement of gas

permeability of polymers. II. Apparatus for determi-

nation of permeabilities of mixed gases and vapors,

J. Appl. Polym. Sci. 20,287–301(1976)

7.294 K.C. O’Brien, W.J. Koros, T.A. Barbari, E.S. Sanders:

A new technique for the measurement of multi-

component gas transport through polymeric ﬁlms,

J. Membr. Sci. 29, 229–238 (1986)

7.295 ASTM Standards F 1307: Standard Test Method for

Oxygen Transmission Rate Through Dry Packages Us-

ing a Coulometric Sensor (ASTM, West Conshohocken

2002)

Part C 7

Mechanical Properties References 451

7.296 W.J. Koros, D.R. Paul: Design considerations for

measurement of gas sorption in polymers by

pressure decay, J. Polym. Sci. B 14,1903–1907

(1976)

7.297 V.I. Bondar, B.D. Freeman, I. Pinnau: Gas sorp-

tion and characterization of poly(ether-b-amide)

segmented block copolymers, J. Polym. Sci. B 37,

2463–2475 (1999)

7.298 J.H. Dymond, E.B. Smith: The Virial Coefﬁcients of

Pure Gases and Mixtures: A Critical Compilation (Ox-

ford Univ. Press, New York 1980)

7.299 C.M.Zimmerman,A.Singh,W.J.Koros:Diffusion

in gas separation membrane materials: A com-

parison and analysis of experimental characteri-

zation techniques, J. Polym. Sci. B 36, 1747–1755

(1998)

7.300 C.C. McDowell, D.T. Coker, B.D. Freeman: An au-

tomated spring balance for kinetic gravimetric

sorption of gases and vapors in polymers, Rev. Sci.

Instrum. 69, 2510–2513 (1998)

7.301 S.N. Dhoot, B.D. Freeman: Kinetic gravimetric sorp-

tion of low volatility gases and vapors in polymers,

Rev. Sci. Instrum. 74, 5173–5178 (2003)

7.302 B. Wong, Z. Zhang, Y.P. Handa: High-presion gravi-

metric technique for determing the solubility and

diffusivity of gases in polymers, J. Polym. Sci. B 36,

2025–2032 (1998)

7.303 S. Areerat, E. Funami, Y. Hayata, D. Naka-

gawa, M. Ohshima: Measurement and prediction

of diffusion coefﬁcients of supercritical CO

molten polymers, Polym. Eng. Sci. 44,1915–1924

(2004)

7.304 Y. Wu, P. Akoto-Ampaw, M. Elbaccouch, M.L. Hurrey,

S.L. Wallen, C.S. Grant: Quartz crystal microbalance

(QCM) in high-pressure carbon dioxide (CO

): Exper-

imental aspects of QCM theory and CO

adsorption,

Langmuir 20, 3665–3673 (2004)

7.305 R. Zhou, D. Schmeisser, W. Gopel: Mass sensitive

detection of carbon dioxide by amino group-

functionalized polymers, Sens. Actuators B 33,

188–193 (1996)

7.306 A.Y. Alentiev, V.P. Shantarovich, T.C. Merkel,

V.I. Bondar, B.D. Freeman, Y.P. Yampolskii: Gas and

vapor sorption, permeation, and diffusion in glassy

amorphous teﬂon AF1600, Macromolecules 35,9513–

9522 (2002)

7.307 ASTM Standards D 1434: Standard Test Method

for Determining Gas Permeability Characteristics

of Plastic Film and Sheeting (ASTM, West Con-

shohocken, Pennsylvania 2003), Originally Approved

in 1982

7.308 ASTM Standards D 3985: Standard Test Method for

Oxygen Gas Transmission Rate Through Plastic Film

and Sheeting Using a Coulometric Sensor (ASTM,

West Conshohocken 2002)

7.309 ASTM Standards F 1927: Standard Test Method for

Determination of Oxygen Gas Transmission Rate,

Permeability and Permeance at Controlled Relative

Humidity Through Barrier Materials Using a Coulo-

metric Detector (ASTM, West Conshohocken 2004),

Approved in 1998

7.310 ASTM Standards E 96: Standard Test Methods for

Water Vapor Transmission of Materials (ASTM, West

Conshohocken 2002)

7.311 ASTM Standards E 398: Standard Test Method for

Water Vapor Transmission Rate of Sheet Mater-

ials Using Dynamic Relative Humidity Measurement

(ASTM, West Conshohocken 2003)

7.312 ASTM Standards E 1770: Standard Practice for Op-

timization of Electrothermal Atomic Absorption

Spectrometric Equipment (ASTM, West Conshohocken

2001), Approved in 1995

7.313 ASTM Standards F 1769: Standard Test Method for

Measurement of Diffusivity, Solubility, and Perme-

ability of Organic Vapor Barriers Using a Flame

Ionization Detector (ASTM, West Conshohocken

2004), Approved in 1997

7.314 E.S. Sanders, W.J. Koros, H.B. Hopfenberg, V. Stan-

nett: Mixed gas sorption in glassy polymers:

Equipment design considerations and preliminary

results, J. Membr. Sci. 13,161–174(1983)

7.315 G.T. Fieldson, T.A. Barbari: Analysis of diffusion in

polymers using evanescent ﬁeld spectroscopy, AIChE

Journal 41, 795–804 (1995)

7.316 R.A. Assink: Investigation of the dual mode sorption

of ammonia in polystyrene by NMR, J. Polym. Sci. B

13, 1665–1673 (1975)

7.317 W.J. Koros, A.H. Chan, D.R. Paul: Sorption and trans-

port of various gases in polycarbonate, J. Membr. Sci.

2, 165–190 (1977)

7.318 S.Y. Lee, B.S. Minhas, M.D. Donohue: Effect of gas

composition and pressure on permeation through

cellulose acetate membranes, AIChE Symp. Ser. 84,

93–101 (1988)

7.319 D.R. Paul, D.R. Kemp: The diffusion time lag in

polymer membranes containing adsorptive ﬁllers,

J. Polym. Sci. Symp. 41, 79–93 (1973)

7.320 H.W. Clever, R. Battino: The solubility of gases in

liquids, Tech. Chem. 8, 379–441 (1975)

7.321 R.T. Yang: Gas Separation by Adsorption Processes

(Butterworths, Boston 1987)

7.322 N.L. Rosi, J. Eckert, M. Eddaoudi, D.T. Vodak, J. Kim,

M.O’Keeffe,O.M.Yaghi:Hydrogenstorageinmi-

croporous metal-organic frameworks, Science 300,

1127–1129 (2003)

7.323 X. Wang, K.M. Lee, Y. Lu, M.T. Stone, I.C. Sanchez,

B.D. Freeman: Modeling transport properties in high

free volume glassy polymers, New Polymeric Mater-

ials, ACS Symp. Ser. 916, 187 (2004)

7.324 E. Tocci, D. Hofmann, D. Paul, N. Russo, E. Drioli:

A molecular simulation study on gas diffusion in

a dense poly(ether-ether-ketone) membrane, Poly-

mer 42, 521–533 (2001)

7.325 EN 10225:2001: Annex E, Weldability Testing for Steels

of Groups 2 and 3 and Mechanical Testing of Butt

Welds (CEN, Brussels 2001)

Part C 7

452 Part C Materials Properties Measurement

7.326 BS 7448-1997: Fracture Mechanics Toughness Tests,

Part II: Method for Determination of K

, Critical CTOD

and Critical J Values of Welds in Metallic Materials

(British Standard Institution, London 1997)

7.327 R.D. Raharjo, B.D. Freeman, E.S. Sanders: Pure and

mixed gas CH

and n-C

sorption and dilation

in poly(dimethylsiloxane), J. Membr. Sci. 292,45–61

(2007)

7.328 C.P. Riberiro, B.D. Freeman: Carbon dioxide/ethane

mixed-gas sorption and dilation in a cross-linked

poly(ethylene oxide) copolymer, Polymer 51, 1156–

1168 (2010)

Part C 7

453

Thermal Prop

8. Thermal Properties

If materials – solids, liquids or gases – are heated

or cooled, many of their properties change. This

is due to the fact that thermal energy supplied to

or removed from a specimen will change either

the kinetic or the potential energy of the con-

stituent atoms or molecules. In the ﬁrst case, the

temperature of the specimen is changed, since

temperature is a measure of the average kinetic

energy of the elementary particles of a sample.

In the second case, e.g. the binding energy of

these particles is altered, which may cause a phase

transition.

Thermal properties are associated with

a material-dependent response when heat is

supplied to a solid body, a liquid, or a gas. This re-

sponse might be a temperature increase, a phase

transition, a change of length or volume, an initi-

ation of a chemical reaction or the change of some

other physical or chemical quantity.

Basically, almost all of the other materials

properties treated in Part C, namely mechani-

cal, electrical, magnetic, or optical properties, are

temperature-dependent (except a material that is

especially designed to be resistant to temperature

variations). For example, temperature inﬂuences

mechanical hardness, electrical resistance, mag-

netism, or optical emissivity. Temperature is also

of importance to the characterization of mater-

ial performance (Part D) as it inﬂuences materials

integrity when subject to corrosion, friction and

wear, biogenic impact or material–environment

interactions. Temperature effects related to these

areas are dealt with in the other chapters of this

book dedicated to those topics. Only if those prop-

erties are needed to explain measuring methods

within this chapter are they are outlined in the

following sections.

In this chapter, a number of materials prop-

erties are selected and called thermal properties,

where the effect of thermal energy treatment plays

the major role compared to electrical, magnetic,

chemical or other effects. The presentation

of measurement methods for thermal properties is

organized into ﬁve parts, referring to:

1. Thermal transport properties, such as thermal

conductivity, thermal diffusivity or speciﬁc heat

capacity, characterizing the ability of materials

to conduct, transfer, store and release heat.

2. Phase transitions and chemical reactions of

materials. Various calorimetric methods are

presented, which are used to investigate e.g.

phase transitions, adsorption, and mixing

processes. Typical examples are ﬁrst-order

transitions such as boiling and melting, but

also combustion and solution processes.

3. Physical properties, which are affected when

heat is supplied to a body. The determina-

tion of the temperature dependence of these

quantities requires knowledge of thermal mea-

surement methods. Among the many different

physical quantities the most important for

applications in materials science and engi-

neering are length and its relation to thermal

expansion.

4. Thermogravimetry, which is important in

chemical analysis, see Chap. 4.

5. Temperature measurement methods, since

these techniques are essential for all the

other measurements described above. Tem-

perature scales and the principles, types

and applications of temperature sensors are

compiled.

8.1 Thermal Conductivity

and Speciﬁc Heat Capacity ..................... 454

8.1.1 Steady-State Methods .................. 456

8.1.2 Transient Methods........................ 458

8.1.3 Calorimetric Methods.................... 461

8.2 Enthalpy of Phase Transition, Adsorption

and Mixing .......................................... 462

8.2.1 Adiabatic Calorimetry ................... 464

8.2.2 Differential Scanning Calorimetry ... 465

Part C 8

454 Part C Materials Properties Measurement

8.2.3 Drop Calorimetry .......................... 466

8.2.4 Solution Calorimetry ..................... 467

8.2.5 Combustion Calorimetry ................ 468

8.3 Thermal Expansion

and Thermomechanical Analysis ............ 469

8.3.1 Optical Methods ........................... 469

8.3.2 Push Rod Dilatometry ................... 470

8.3.3 Thermomechanical Analysis........... 470

8.4 Thermogravimetry ................................ 471

8.5 Temperature Sensors ............................ 471

8.5.1 Temperature

and Temperature Scale ................. 471

8.5.2 Use of Thermometers .................... 474

8.5.3 Resistance Thermometers .............. 475

8.5.4 Liquid-in-Glass Thermometers ...... 477

8.5.5 Thermocouples ............................ 478

8.5.6 Radiation Thermometers ............... 479

8.5.7 Cryogenic Temperature Sensors ...... 480

References .................................................. 482

8.1 Thermal Conductivity and Speciﬁc Heat Capacity

There are two main material properties (thermophysi-

cal properties) associated with heat transfer in materials.

These are the ability of a material to store heat and

the ability to transfer heat by conduction. If a speciﬁc

amount of heat dQ is supplied to a thermally isolated

specimen of mass m the relationship between heat and

temperature increase dT is given by

dQ = mc

dT . (8.1)

Consequently the ability of a material to store heat is

characterized by the speciﬁc heat capacity at constant

pressure c

. If two equal volumes of different mater-

ials are compared to each other, the ability to store

heat is described by the product of density and speciﬁc

heat capacity c

. This product is used if simultaneous

heat conduction and storage processes are investigated

by means of the transient heat conduction equation. In

many cases the density of a material or the mass of

a specimen is well known or can be easily determined

with sufﬁcient accuracy. Therefore, the problem is re-

duced to the determination of the speciﬁc heat capacity.

For gases and some liquids a distinction between the

speciﬁc heat capacity at constant pressure c

and at

constant volume c

is made. This is due to the work

required for the thermal expansion of the gas or liquid.

For solids this contribution is very small in comparison

to the measurement uncertainty and can be neglected.

The thermal conductivity λ is the material prop-

erty associated with heat conduction and is deﬁned by

Fourier’s law

q =−λ

∂T

∂x

=−λ

ΔT

. (8.2)

Here, q is the heat ﬂux, the heat conducted during

a unit time through a unit area, driven by a temperature

gradient ∂T/∂x. In practice, for thermal conductivity

measurements the temperature difference ΔT between

two opposite surfaces of a sample with a separation of d

is determined. The quotient of distance and thermal con-

ductivity is the thermal resistance R

. In contrast to the

storage of heat, conduction is considered as a steady-

state process, i. e. the temperature ﬁeld and the heat ﬂux

within heat-conducting materials are not a function of

time.

But, in most cases both heat conduction and heat

storage are simultaneously occurring processes. This

is taken into account by the transient heat conduction

equation. The temperature ﬁeld T(x, t) in one dimen-

sion is dependent on the location x and time t

∂T

∂t

∂

∂x

. (8.3)

The thermal diffusivity a is given as the ratio of the ther-

mal conductivity and the product of density and speciﬁc

heat capacity

a =

c

. (8.4)

From its physical meaning thermal diffusivity is asso-

ciated with the speed of heat propagation. In analogy

to Einstein’s relation, which connects random walks

and diffusion, the mean square displacement





a thermal pulse is proportional to the observation time t

(one-dimensional diffusion)

a =





. (8.5)

A further thermal property is the thermal effusivity e.

The thermal effusivity is a measure of a material’s abil-

Part C 8.1

Thermal Properties 8.1 Thermal Conductivity and Speciﬁc Heat Capacity 455

ity to exchange heat with the environment (thermal

impedance) and is deﬁned according to

e =



λc

. (8.6)

Knowing the thermal diffusivity and thermal effusivity,

other complementary materials properties, e.g. λ and

c

, can be calculated.

Based on the fundamental laws of heat conduc-

tion and storage three different attempts to measure

these thermophysical properties can be distinguished.

The ﬁrst one is the steady-state approach using (8.2)

in order to determine the thermal conductivity. Steady-

state conditions mean that the temperature at each point

of the sample is constant, i. e. not a function of time.

The determination of the thermal conductivity is based

on the measurement of a heat ﬂux and a temperature

gradient, i. e. mostly a temperature difference between

opposite surfaces of a sample. If the speciﬁc heat cap-

acity is the property of interest, a calorimetric method

Table 8.1 Comparison of measurement methods for the determination of thermal conductivity and thermal diffusivity

Method Temperature Uncertainty Materials Merit Demerit

range

Guarded hot 80–800 K 2% Insulation materials, High accuracy Long measurement time,

plate plastics, glasses large specimen size,

low conductivity materials

Cylinder 4–1000 K 2% Metals Temperature range, Long measurement time

simultaneous determination of

electrical conductivity and

Seebeck-coefﬁcient possible

Heat ﬂow meter −100–200

◦

C 3–10% Insulation materials, Simple construction Measurement uncertainty,

plastics, glasses, and operation relative measurement

ceramics

Comparative 20–1300

◦

C 10–20% Metals, ceramics, Simple construction Measurement uncertainty,

plastics, plastics and operation relative measurement

Direct heating 400–3000 K 2–10% Metals Simple and fast measurements, Only electrically

(Kohlrausch) simultaneous determination conducting materials

of electrical conductivity

Pipe method 20–2500

◦

C 3–20% Solids Temperature range Specimen preparation,

long measurement time

Hot wire, 20–2000

◦

C 1–10% Liquids, gases, low Temperature range, Limitedtolow

hot strip conductivity solids fast, accuracy conductivity materials

Laser ﬂash −100–3000

◦

C 3–5% Solids, liquids Temperature range, most Expensive, not for

solids, liquids and powders, insulation materials

small specimen, fast, accuracy

at high temperatures

Photothermal 30–1500 K Not sufﬁ- Solids, liquids, Usable for thin ﬁlms, Nonstandard, knowledge

photoacoustic

ciently gases, thin ﬁlms liquids and gases about accuracy

known

based on (8.1) is used. In this case, heat is supplied

to a sample that is isolated from the surroundings,

and the change of the (mean) sample temperature is

measured. The third approach is the simultaneous de-

termination of both properties by a transient technique.

For that purpose numerous solutions of the transient

heat conduction equation based on one- (8.3), two-, or

three-dimensional geometries have been derived.

The main experimental problem for all methods for

the determination of thermal properties is that ideal ther-

mal conductors or insulators do not exist. In comparison

to electrical transport the ratio of thermal conductivities

of the best conductors and the best insulators is many or-

ders of magnitudes smaller. Therefore, instruments for

the determination of thermal properties are often opti-

mized or restricted for a speciﬁc class of materials or

temperature range [8.1]. Table 8.1 gives an overview of

the most important methods used for the measurement

of thermal conductivity and thermal diffusivity.

Part C 8.1

456 Part C Materials Properties Measurement

8.1.1 Steady-State Methods

The principle of (one-dimensional) steady-state methods

for the determination of the thermal conductivity is de-

rived from (8.2) and based on the measurement of a heat

ﬂux and a temperature difference according to

λ =

−T

A (T

−T

)

. (8.7)

In many cases the heat ﬂux q is determined by the meas-

urement of a power P released in an electrical heater

divided by the area A of the sample. The temperature

difference T

−T

is determined between two opposite

surfaces of the specimen having a separation of d.

The typical sample geometry and the conﬁgura-

tion of a measurement system for thermal conductivity

measurements depend most strongly on the magnitude

of the thermal conductivity. When the thermal conduc-

tivity of a material is low, the samples are usually ﬂat

disks or plates. In the case of a high thermal conduc-

tivity the sample geometry is formed by a cylinder or

rod. According to the relationship between the sample

geometry (assumed to be cylindrical) and the direction

of the heat ﬂow, axial and radial heat ﬂow methods of

measuring the thermal conductivity are distinguished.

Guarded Hot Plate and Cylinder Method

The guarded hot plate method can be used for the de-

termination of the thermal conductivity of nonmetals

such as glasses, ceramics, polymers and thermal insu-

lation materials but also for liquids and gases in the

temperature range between about 80 K and 800 K. The

geometry of the sample or sample chamber is a plate

or a cylinder with axial heat ﬂow. Depending on the

thermal conductivity and homogeneity of the material

under investigation, the sample thickness varies be-

tween a few millimeters and a few decimeters. There are

two different types of guarded hot plate instruments: the

Guarded heater

hot plate

Specimen

Cold-plate

Insulation

Auxiliary heater

Fig. 8.1a,b Principle of the guarded hot plate method. (a) two-

specimen apparatus.

(b) single-specimen apparatus

two-specimen and the single-specimen apparatus shown

in Fig. 8.1.

Guarded hot plate instruments consist of one or two

cold plates, a hot plate and a system of guard heaters and

thermal insulation. The cold plates are liquid-cooled

heat sinks, the hot plate is electrically heated. To make

sure that the heat released in the hot plate is passed only

through the sample, the hot plate is surrounded by guard

heaters and thermal insulation. This minimizes the heat

losses from the hot plate and ensures the high accu-

racy of this method. With guarded hot plate instruments

relative expanded uncertainties of thermal conductivity

measurements of about 2% can be achieved. There are

two main sources of uncertainty in thermal conductivity

measurements: the heat ﬂux and the temperature dif-

ference determination. The major contributions to heat

ﬂux errors are heat losses from the hot plate and the

heat exchange between the sample and the surround-

ing medium. With increasing thermal resistance of the

sample (insulation materials) these sources of uncer-

tainty become dominant.

The advantage of the two-specimen apparatus is

that heat losses from the hot plate can be controlled

more effectively because of the symmetric specimen ar-

rangement. In contrast to the single-specimen method,

only solid materials can be investigated. This is because

of the inﬂuence of convection on thermal conductivity

measurements. In order to avoid convection, the sample

must be heated from the top.

The cylinder method with axial heat ﬂow can be

used for thermal conductivity measurements of met-

als with thermal conductivities up to 500 W m

−1

in a temperature range between about 4 K and 1000 K.

Comparing the principle of operation and the mathe-

matical model, the cylinder method and the guarded

hot plate method fully agree. The most important dif-

ference is the sample geometry, which is a ﬂat plate or

disk for the guarded hot plate method and a long cylin-

der or rod for the cylinder method. This is due to the

fact that the main difﬁculty for measurements of ma-

terials with high thermal conductivity (e.g. metals) is

the determination of the temperature difference. In this

case the contact resistances between the sample and the

heater and between the sample and the cold plate must

be considered. The minimization and determination of

the resulting temperature drop across these thermal con-

tact resistances is the most important criterion for the

optimization of this type of instrument.

Therefore, guarded hot plate and cylinder method

are realizations of the same measurement principle op-

timized for different ranges of thermal conductivity.

Part C 8.1

Thermal Properties 8.1 Thermal Conductivity and Speciﬁc Heat Capacity 457

Heat Flow Meter and Comparative Method

The main disadvantage of steady-state methods is that

they are very time consuming. This is because the whole

system of specimen and guard heaters must reach ther-

mal equilibrium in order to avoid unaccounted heat

losses and deviations from steady-state conditions. The

basic idea of the heat ﬂow meter and the comparative

method is the determination of the (axial) heat ﬂux by

means of the measurement of a temperature drop across

a thermal resistor. This is in analogy to the determi-

nation of a current by the measurement of a voltage

drop across an electrical resistor. The implementation

of this idea for heat ﬂux measurements is carried out ei-

ther by the use of a reference sample with well-known

(certiﬁed) thermal resistance or by means of a heat ﬂux

sensor. Most heat ﬂux sensors consist of a series con-

nection of thermocouples across a thermal resistor, e.g.

a thin ceramic or plastic plate. The measured signal is

a thermovoltage proportional to the temperature drop

across the plate. Usually a heat ﬂux sensor is calibrated

in a steady-state temperature ﬁeld with well-known heat

ﬂux, e.g. in a guarded hot plate apparatus.

The design of a heat ﬂow meter apparatus is very

similar to that of the single-specimen guarded hot plate

instrument. Instead of the main heater a heat ﬂux sensor

is used. In some cases a second heat ﬂux sensor at the

cold plate is applied to determine radial heat losses and

to reduce the measurement duration. This is of particu-

lar advantage for measurements of insulation materials.

To avoid radial heat losses the lateral surfaces of the

sample are surrounded by thermal insulation or addi-

tional guard heaters.

If a reference sample for heat ﬂux measurements is

used, the sample and reference samples are piled upon

one another in a temperature ﬁeld (series connection of

thermal resistors). The temperature drops across both

sample and reference sample are measured and com-

pared (comparative method). To correct for radial heat

losses two reference samples are mostly used and the

investigated sample is sandwiched between them. Un-

der steady-state conditions the heat ﬂux at each point

of the stack is the same. In that case the ratio of the

thermal resistances of the sample and reference sample

is equal to the ratio of the corresponding temperature

drops. In contrast to the guarded hot plate method the

heat ﬂow meter and the comparative method are relative

and not absolute methods. The heat ﬂow meter method

is mostly used for insulation materials and polymers

(λ<0.3Wm

−1

), in some cases for glasses and ce-

ramics, i. e. for materials with thermal conductivities

less than about 5 W m

−1

. In contrast, the typical

application range of the comparative technique is the

investigation of metals, ceramics and glasses having

thermal conductivities above 1 W m

−1

. Typical up-

per temperature limits are about 200

◦

C for the heat ﬂow

meter method and about 1300

◦

C for the comparative

method. The measurement uncertainties are about 3%

for insulation materials near room temperature and be-

tween 10 and 20% at high temperatures.

Direct Heating (Kohlrausch) Method

The disadvantages of steady-state thermal conductivity

measurement methods are the long equilibration time

needed to reach steady-state conditions and the difﬁ-

cult quantiﬁcation of heat losses, in particular at high

temperatures. These can be avoided using the direct

heating method, although this can only be used for

materials with sufﬁciently high electrical conductivity,

such as metals. Typically samples are wires, pipes or

rods with a diameter d between 0.5 and 20 mm and

a length l between 50 and 500 mm. Figure 8.2 shows

the schematic of the most popular design of the direct

heating method.

The sample is placed in a vacuum chamber, clamped

between two liquid-cooled heat sinks and heated by

a sufﬁciently high electrical current I

to achieve

sample temperatures in the range 400–3000 K. Temper-

atures and voltage drops are measured at three positions;

one position is in the middle of the rod, while the oth-

Power supply

Vacuum

enclosure

Cylindrical

guard heater

guard

Specimen

, T

–U

Fig. 8.2 Principle of the direct heating method

Part C 8.1
