PLANNING, DESIGNING, AND CONSTRUCTING TENSION LEG PLATFORMS 221

The input to the response model is seastate, wind, current, and water level values. Responses to wave H

, T

and direction, current speed and direction, and water level should be accounted for. Wind, wave, and current

vectors may be taken in their true directions rather than assumed coincident during this evaluation. Wave

spreading generally is not considered in extreme environments. Wave frequency effects (spectral peak

frequency and width) should be considered. Setdown with offset should be included for tension, offset, and

deck clearance calculations. Storm surge should be included in the database, while tide contributions should

be handled parametrically by performing calculations at low- and high-tide conditions.

The output of the response model is expected maximum response and variability of response for each of the

global performance responses. The TLP responses to all seastates in the environmental database then form

a secondary database which is linked to the environmental database. This is evaluated in the following steps:

a) using a probability distribution model for extreme values (Weibull Type II or Type III) fit a cumulative

probability distribution function to the response data (for each response);

b) using this fitted distribution, identify the 0.01 annual exceedence probability response.

NOTE This probability should be linked to the true probability distribution accounting for the observation period and

sampling nature of the data set.

The simplified numerical model should be based on the expected value of the extreme response in each

condition. As such, the analysis should not include factors and margins. The results are used in a relative

sense, and are not used directly as design values. The 0.01 annual exceedence probability responses are

notional, and typically will vary from the final design estimates.

A.3.3 Response-based Criteria

From the response data, subsets of storm condition may be identified which produce any given response.

From these subsets of storm conditions, environmental combinations may be identified that provide a

reasonable range of forcing functions for detailed analysis. These will typically include combinations that

cover 0.01 annual exceedence probability levels of wind, wave, and/or current, and steep and/or long period

wave conditions.

It is important that the combinations selected cover a range of environmental parameters so that small

variations in sensitivity of the simple model relative to the final analysis model are accounted for. In practice,

three sets of conditions for each response are considered reasonable, and may be selected so that each

detailed simulation may be used for several responses.

These sets of conditions for each response then form the environmental design criteria to be used in

predicting detailed responses used in the design equations in 7.8.

A.3.4 Special Considerations—Springing and Ringing

High-frequency (springing and ringing) TLP responses are not amenable to numerical simulations, and are

generally best estimated with model tests. Some means should be included in the long-term analysis to

account for high-frequency response contributions to peak loads in the tendon system. A commonly used

method is parameterizing the high-frequency response as a function of wave height and steepness based on

previous model test results, and including a high-frequency estimate for each seastate.

A.3.5 Special Considerations—Eddy Currents

The response based criteria method is especially useful in defining storm condition/eddy current

combinations. Loop current eddies are statistically independent of hurricane events, but the combination can

produce quite high offsets in a TLP. The response-based criteria methods establish a rational and defined

return period event for the combination of eddy and hurricane. This joint event is typically the controlling event

for maximum offset.
