LANNING

ESIGNING

AND

ONSTRUCTING

ENSION

LATFORMS

241

D.4.2.2.5 Section D.4.2.2.1 c) relates to the development of progressive pile failure due to the axial

flexibility of the pile-soil system under cyclic loading conditions. Two-way (i.e. tension-compression) load tests

conducted in the above mentioned studies show an immediate degradation in pile capacity. Results from the

full-scale Beta pile test (Doyle and Pelletier, 1985

[125]

) showed temporary reductions of 61 % to 85 % of the

precyclic pile capacity within 16 fully reversed load cycles. In addition, the weight of the soil plug was not

evident during cyclic testing. However, other testing at Haga by NGI (Karlsrud, K., and Haugen, T., 1981

[165]

)

suggests that one-way cyclic loading of the pile relative to the soil causes significantly less degradation than

two-way loading at discrete pile elevations. For long flexible piles, fully reversed cycling may occur even

though the pile top is under a sustained bias loading. Thus, pile load capacity may be reduced due to cyclic

loading for flexible piles.

D.4.2.2.6 Section D.4.2.2.1 d) considers the effect of sustained tension loading on soil behavior. Soils

under sustained shear stress may deform in time. This effect should be considered in determining the long-

term capacity of piles under sustained loading.

D.4.2.2.7 Section D.4.2.2.1 e) represents a consideration, which can be expected to aid the foundation’s

load carrying capacity. Since here again it is not possible to reliably quantify the effects of suction, it was

decided to ignore this consideration.

D.4.2.3 Lack of Residual Strength of the Soil-pile System

A consideration included under this factor is the relative lack of residual strength for a pile loaded in tension

compared to one loaded in compression. Schematically, the relative residual strength after pile overload in

tension (T), and compression (C) may be viewed as shown in Figure D.1.

The potential for dramatic decreases in strength in the event of pile overload warrants an increased safety

factor when compared to a compression pile. The assignment of specific numerical values to account for a

tension pile’s relative lack of residual strength is uncertain.

Figure D.1—Relative Residual Strength After Pile Overload

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

242 API RECOMMENDED PRACTICE 2T

D.4.2.4 Load Redistribution Capacities of the Foundation

Redundancy in the form of clustered or grouped piles can mitigate concern over the lack of residual strength,

since all piles would not reach their maximum capacity simultaneously. The bias factor should reward

redundancy.

D.4.2.5 Relative Difficulty of Foundation Installation

The relative ability to install satisfactory driven piles is deemed comparable to the skirt piles of a jacket-type

structure. For drilled and grouted piles and for connections between a pile and a foundation template, it is

believed that these should be attainable in a manner comparable to a jacket platform. However, it is believed

necessary to explicitly mention that special means should be provided to verify that grouted piles and pile to

template connections are installed in a manner conforming to the design.

NOTE Provided explicit mention was made of the need to provide means to verify the adequacy of grout and pile to

template connection installation.

D.4.2.6 Relative Integrity of Soil Samples Obtained from Deepwater

In this regard it is believed that adequate precautions are already mentioned in 10.2.2. It is also felt that the

geotechnical consultant in conjunction with the operator’s staff, could properly interpret engineering soil

properties resulting from deepwater soil samples.

D.4.2.7 Relative Character and Reliability of Load Determination

The determination of loading is assumed to be comparable to that obtained for a jacket structure.

D.4.2.8 Relative Lack of Ability to Inspect and Repair TLP Foundation Piles

The ability to inspect and repair TLP piles was deemed to be very similar to that of jacket-type structure.

D.4.3 Consequences of a Foundation Failure to the Integrity of the Overall Structural System

The consequence of a foundation failure for a TLP was deemed to be comparable to that of a jacket-type

structure if a multi-pile bottom template is used to house the tendon receptacles. For the direct-connection

method, pile failure is not comparable to that of a jacket-type structure. The number of piles per corner and

the ultimate capacity of all the piles at the corner should be considered in evaluating the possible failure of a

single pile when the

B-factor is selected.

D.5 Discussion on Large Lateral Pile Deflections

Because it is a free-head pile, the direct-connect method may result in lateral deflections that exceed the

criterion on which API 2A-WSD is based (see Matlock and Tucker, 1961

[186]

and Matlock, 1970

[187]

). The

lateral deflections for the tests at Sabine, for example, did not exceed about 25 % of the pile diameter.

Therefore, in lieu of other data, it may be assumed in clay soils that when lateral deflections (for the pile in the

soil) exceed about 25 % of the pile diameter, the

(i.e. ultimate lateral resistance) given in API 2A-WSD

should be reduced by the ratio of remolded to undisturbed strength and that the cyclic soft clay criteria

governs the shape of the curve. This is based on published model test data and centrifuge tests by Doyle et

al. (2005)

[129]

that indicate a reduced Pu is appropriate when lateral deflections exceed about 25 % of the pile

diameter. In applying this recommendation, the criteria given in API 2A-WSD is followed until the pile

deflection exceeds 25 % of the diameter. At that time the

p-y curves are generated as normal until the value of

p/p

reaches the ratio of the remolded to undisturbed shear strength. At that time, all further values given in

API 2A-WSD for

p/p

shall not exceed the ratio of remolded to undisturbed shear strength. The associated

values of

x/x

shall remain the same.

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

243

Annex E

(informative)

Drilling and Production Interacting Checklists

A good working design is often seriously weakened by a lack of definition between the various design

disciplines on how the drilling rigs interface with the TLP. Drilling rig interface points with TLPs are provided in

Tables E.1 through E.3.

Table E.1—Structure Layout Interface Checklist

Item Structure Layout Interface Point

1 Position and strength of beams and trusses on platform deck(s)

2 Allowable loadings for deck areas between major support members

3 Deck layout plans for open areas

4 Design loads due to wind on drilling packages

5 Dynamic loads from drilling packages resulting from horizontal accelerations of platform

6 Loading conditions from drilling packages due to construction, tow out and temporary

mooring phases

7 CG and weight impact due to rig layouts, drilling live loads, and rig packaging/module

design

8 Rig skid beam spacing, position, and strength

9 Jacking systems that can be accommodated

10 Elevation of well heads

11 Strength and layout of local beams around wellhead area

12 Strength points available for pulling heavy loads; eg, hanging BOP units

13 Position of “rat” and “mouse holes”

14 Access into/out of the hull for equipment when the drill rig is in place

15 Increased accommodation needs

16 Use of brine tanks in the hull

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

244 API RECOMMENDED PRACTICE 2T

Table E.2—Utilities Interface Checklist

Item Utilities Interface Systems and Equipment

1 Sharing with production systems

2 Lightweight machinery valving and piping

3 Area classification requirements resulting from drilling rig modules

4 Liquid storage in hull vs decks—consideration should be give between weight and CG

positive impacts and negative fire and gas and hazardous area effects

5 Piping for fuel, water, etc., and transfer to and along the platform

a) location distribution, size and number

b) access points

6 Electrical power and communication/instrumentation

a) quantity, distribution and location of cables

b) remote bop control points (including prerun hydraulic lines)

c) drilling instrumentation

Table E.3—Rig Services Interface Checklist

Item Utilities Interface Systems and Equipment

1 Drilling drains, sumps, and solids handling to avoid coating or plugging lines, sumps, or

other discharge points

a) down comers for overboard disposal of cuttings from shale shakers, desilters,

desanders, and sand traps

b) drilling mud from active and reserve mud pits

c) cement and cooling water

2 Impact of solid discharges on underwater equipment structures or intakes

3 Supply barge handling and consumable loading/unloading

4 Handling and operations of drilling risers, blowout preventers and deep well tools

5 Penetrations through the hull to be used for acoustical positioning equipment (serious

consideration should be given to locating this type of system outside the hull)

6 ROV interfaces ROVs shall be able to plug all penetrations ROVs are limited in the

amount of direct overhead work they can do and penetration design shall keep this in

mind

7 Maintenance and operations of equipment used by the drilling team but located in the

hull in areas that affect watertight integrity shall be agreed by both teams

8 If used, the weight of brine and the possibility and impacts of tank overflowing shall be

considered both by the structural group and the marine systems group

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

245

Annex F

(informative)

Regulations Governing TLPs

F.1 USCG Regulations for TLPs Located in U.S. Waters

Applicable regulations for TLPs in U.S. waters include the following.

a) 33 CFR Parts 140 to 147 (Subchapter N), Outer Continental Shelf Activities. These regulations stipulate

requirements for identification marks for platforms, means of escape, guard rails, fire extinguishers, life

preservers, ring buoys, first aid kits, etc.

b) 46 CFR Parts 107 to 109 (Subchapter IA), Mobile Offshore Drilling Units. These regulations govern the

inspection and certification design and equipment and operation.

c) 46 CFR Parts 50 to 64 (Subchapter F), Marine Engineering. These regulations prescribe the

requirements for materials construction, installation, inspection and maintenance of boilers, unfired

pressure vessels, piping and welding.

d) 46 CFR Parts 110 to 113 (Subchapter J), Electrical Engineering. These regulations prescribe in detail the

electrical engineering requirements for vessels.

e) 33 CFR Part 67, Aids to Navigation on Artificial Islands and Fixed Structures. These regulations prescribe

in detail the requirements for installation of lights and foghorns on offshore structures in various zones.

f) Oil and Pollution Act (OPA 90); governs storage of hydrocarbons at the waterline.

g) Minerals Management jurisdiction for TLPs located in U.S. waters

⎯30 CFR Part 250⎯oil and gas and

sulfur operations in the outer continental shelf and outer continental shelf orders for U.S. waters. These

orders govern the marking, installation, operation, and removal of offshore structures and facilities.

F.2 International Regulations

Applicable international regulations include the following:

a) International Maritime Organization (IMO), Code for the Construction and Equipment of Mobile Offshore

Drilling Units [Resolution A.414 (XI)].

b) International Regulations for Preventing Collisions at Sea, Rule 24a, Towing and Pushing.

c) International Electrical Code (IEC).

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

246

Bibliography

[1] API Recommended Practice 2A-WSD (21st Edition), Recommended Practice for Planning, Designing

and Constructing Fixed Offshore Platforms— Working Stress Design

[2] API Recommended Practice 2A-LRFD, Recommended Practice for Planning, Designing and

Constructing Fixed Offshore Platforms—Load and Resistance Factor Design

[3] API Specification 2C, Offshore Cranes

[4] API Specification 2B, Fabricated Structural Steel Pipe

[5] API Recommended Practice 2G (historical), Recommended Practice for Production Facilities on

Offshore Structures

[6] API Bulletin 2INT-MET, Interim Guidance on Hurricane Conditions in the Gulf of Mexico

[7] API Recommended Practice 2RD, Design of Risers for Floating Production Systems (FPSs) and

Tension-Leg Platforms (TLPs)

[8] API Recommended Practice 2SK, Design and Analysis of Stationkeeping Systems for Floating

Structures

[9] API Bulletin 2U, Stability Design of Cylindrical Shells

[10] API Bulletin 2V, Design of Flat Plate Structures

[11] API Recommended Practice 2X, Ultrasonic and Magnetic Examination of Offshore Structural

Fabrication and Guidelines for Qualification of Technicians

[12] API Recommended Practice 2Z, Preproduction Qualification for Steel Plates for Offshore Structures

[13] API Recommended Practice 14C, Analysis, Design, Installation and Testing of Basic Surface Safety

Systems on Offshore Production Platforms

[14] API Recommended Practice 14E, Recommended Practice for Offshore Production Platform Piping

Systems

[15] API Recommended Practice 14F, Recommended Practice for Design and Installation of Electrical

Systems for Offshore Production Platforms

[16] API Recommended Practice 14G, Recommended Practice for Fire Prevention and Control on Open

Type Offshore Production Platforms

[17] API Recommended Practice 17A, Design and Operation of Subsea Production Systems—General

Requirements and Recommendations

[18] API Recommended Practice 17B, Recommended Practice for Flexible Pipe

[19] API Specification 17D, Subsea Wellhead and Christmas Tree Equipment

[20] API Specification 17E, Specification for Subsea Umbilicals

[21] API Recommended Practice 17G, Recommended Practice for Completion/Workover Risers

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

PLANNING, DESIGNING, AND CONSTRUCTING TENSION LEG PLATFORMS 247

[22] API Specification 17J, Specification for Unbonded Flexible Pipe

[23] API Recommended Practice 16Q, Design, Selection, Operation, and Maintenance of Marine Drilling

Riser Systems

[24] API Recommended Practice 505, Classifications of Locations for Electrical Installations at Petroleum

Facilities Classified as Class 1, Zone 0, Zone 1 and Zone 2

[25] API Recommended Practice 520 (All Parts), Sizing, Selection, and Installation of Pressure Relieving

Systems in Refineries

[26] API Recommended Practice 521, Guide for Pressure Relief and Depressuring Systems

[27] API 607, Testing of Valves—Fire Type-testing Requirements

[28] API Recommended Practice 1111, Design, Construction, Operation, and Maintenance of Offshore

Hydrocarbon Pipeline and Risers

[29] ABS 2 (All Parts)

, Rules for Building and Classing Steel Vessels

[30] ABS 6 (All Parts), Rules for Building and Classing Mobile Offshore Drilling Units

[31] ABS 29, Rules for Building and Classing Offshore Installations

[32] ABS 82, Guide for Building and Classing Floating Production Installations

[33] ABS 115, Guide for the Fatigue Assessment of Offshore Structures

[34] AISC 325-05

, Manual of Steel Construction—Allowable Stress Design

[35] AISC 360-05, Specification for the Design, Fabrication and Erection of Structural Steel for Buildings

[36] ASME Boiler and Pressure Vessel Code (BVPC)

, Section VIII: Rules for Construction of Pressure

Vessels, Division 2: Alternative Rules

[37] ASME B31.1, Power Piping

[38] ASME B31.3, Process Piping

[39] ASME B31.4, Pipeline Transportation Systems for Liquid Hydrocarbons and Other Liquids

[40] ASME B31.8, Gas Transmission and Distribution Piping Systems

[41] ASTM A6

, Standard Specification for General Requirements for Rolled Structural Steel Bars, Plates,

Shapes, and Sheet Piling

[42] ASTM A139, Standard Specification for Electric-Fusion (Arc)-Welded Steel Pipe (NPS 4 and Over)

[43] ASTM A370, Standard Test Methods and Definitions for Mechanical Testing of Steel Products

American Bureau of Shipping, ABS Plaza, 16855 Northchase Drive, Houston, Texas 77060, www.eagle.org.

American Institute of Steel Construction, One East Wacker Drive, Suite 700, Chicago, Illinois 60601, www.aisc.org.

ASME International, 3 Park Avenue, New York, New York 10016-5990, www.asme.org.

ASTM International, 100 Barr Harbor Drive, West Conshohocken, Pennsylvania 19428, www.astm.org.

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

248 API RECOMMENDED PRACTICE 2T

[44] ASTM A381, Standard Specification for Metal-Arc-Welded Steel Pipe for Use With High-Pressure

Transmission Systems

[45] ASTM A450, Standard Specification for General Requirements for Carbon and Low

Alloy Steel Tubes

[46] ASTM A671, Standard Specification for Electric-Fusion-Welded Steel Pipe for Atmospheric and Lower

Temperatures

[47] ASTM D412, Standard Test Methods for Vulcanized Rubber and Thermoplastic Elastomers—Tension

[48] ASTM D429, Standard Test Methods for Rubber Property—Adhesion to Rigid Substrates

[49] ASTM D624, Standard Test Method for Tear Strength of Conventional Vulcanized Rubber and

Thermoplastic Elastomers

[50] ASTM D2240, Standard Test Method for Rubber Property—Durometer Hardness

[51] AWS D1.1

, Structural Welding Code

[52] BSI BS 7910:1999

, Guide on Methods for Assessing the Acceptability of Flaws in Fusion Welded

Structures.

[53] BSI BS 7608:1993, Fatigue Design and Assessment of Steel Structures

[54] DNV-OS-C103

, Structural Design of Column-stabilised Units (LRFD method)

[55] DNV-OS-C105, Structural Design of TLP’s (LRFD method)

[56] DNV-OS-C201, Structural Design of Offshore Units (WSD method)

[57] DNV-OSS-101, Rules for Classification of Offshore Drilling and Support Units

[58] DNV-OSS-102, Rules for Classification of Floating Production and Storage Units

[59] DNV-RP-C103, Column Stabilised Units

[60] DNV-RP-C201, Buckling Strength of Plated Structures

[61] DNV-RP-C202, Buckling Strength of Shells

[62] DNV-RP-C203, Fatigue Strength Analysis of Offshore Steel Structures

[63] DNV-RP-C205, Environmental Conditions and Environmental Load

[64] FAA Advisory Circular 100/5390-1B

, Heliport Design Guide

[65] IEEE Standard 45

, Recommended Practice for Electric Installations on Shipboard

American Welding Society, 550 NW LeJeune Road, Miami, Florida 33126, www.aws.org.

British Standards Institution, Chiswick High Road, London, W4 4AL, United Kingdom, www.bsi-global.com.

Det Norske Veritas, Veritasveien 1, 1322, Hovik, Oslo, Norway, www.dnv.com.

Federal Aviation Administration, 800 Independence Avenue, S.W., Washington, DC 20591, www.faa.gov.

Institute of Electrical and Electronics Engineers, 445 Hoes Lane, Piscataway, New Jersey 08854, www.ieee.org.

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

PLANNING, DESIGNING, AND CONSTRUCTING TENSION LEG PLATFORMS 249

[66] IMO MARPOL 73/78

, International Convention for the Prevention of Pollution From Ships, 1973 as

Modified by the Protocol of 1978

[67] IMO SOLAS, Safety of Life at Sea

[68] ISO 19901-4

, Petroleum and natural gas industries

⎯

Specific requirements for offshore

structures

⎯

Part 4: Geotechnical and foundation design considerations

[69] ISO 19901-5, Petroleum and natural gas industries

⎯

Specific requirements for offshore

structures

⎯

Part 5: Weight control during engineering and construction

[70] ISO 19902, Petroleum and natural gas industries—Fixed steel offshore structures

[71] ISO 19904-1, Petroleum and natural gas industries—Floating offshore structures–Part 1: Monohulls,

semisubmersibles and spars

[72] NFPA, Fire Protection Handbook

[73] NFPA 1, Fire Code

[74] NFPA 70, National Electrical Code

[75] SNAME T&R Bulletin 4-16

, Recommended Practices for Merchant Ship Heating, Ventilation and Air

Conditioning Design Calculations

[76] SSC 266

, Review of Ship Structural Details

[77] SSC 272, In-Service Performance of Structural Details

[78] SSC 294, Further Survey of In-Service Performance of Structural Details

[79] USCG COMDTINST 16000.7A

, Marine Safety Manual, Volume II, Materiel Inspection

[80] USCG NVIC 6-72, Guide to Fixed Fire-Fighting Equipment Aboard Merchant Vessels

[81] USCG NVIC 9-97, Guide to Structural Fire Protection

[82] Manual of Safe Practices in Offshore Operations

, International Association of Drilling Contractors,

Offshore Operator’s Committee, 1972

[83] OPA 90

, U.S. Oil Pollution Act of 1990, 101 H.R.1465, Public Law 101-380

International Maritime Organization, 4 Albert Embankment, London, United Kingdom, www.imo.org.

International Organization for Standardization, 1, ch. de la Voie-Creuse, Case postale 56, CH-1211, Geneva 20,

Switzerland, www.iso.org.

National Fire Protection Association, 1 Batterymarch Park, Quincy, Massachusetts 02169-7471, www.nfpa.org.

The Society of Naval Architects and Marine Engineers, 601 Pavonia Avenue, Jersey City, New Jersey 07306,

www.sname.org

Ship Structure Committee, U.S. Coast Guard, 2100 Second Street, S.W., Washington, DC 20593,

www.shipstructure.org.

U.S. Coast Guard Marine Safety Center (part of DOT), 2100 Second Street, S.W., Washington, DC 20593,

www.uscg.mil.

International Association of Drilling Contractors, P.O. Box 4287, Houston, Texas 77210, www.iadc.org.

U.S. Environmental Protection Agency, Ariel Rios Building, 1200 Pennsylvania Avenue, Washington, DC 20460,

www.epa.gov.

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---

250 API RECOMMENDED PRACTICE 2T

[84] 33 CFR, Navigation and Navigable Waters, Part 142

⎯

Workplace Safety and Health,

Part 144

⎯

Lifesaving Appliances, Part 146

⎯

Operations

[85] 46 CFR Part 108

⎯

Shipping

⎯

Design and Equipment, Part 111

⎯

Shipping–Electric Systems

⎯

General

Requirements, Part 113

⎯

Communication and Alarm Systems and Equipment

[86] Allen D. W. and Henning, D. L., “Prototype VIV Tests for Production Risers,” OTC 13114, 2001

Offshore Technology Conference, Houston, Texas

[87] Allen, D. W., “Performance Characteristics of Short Fairings,” Offshore Technology Conference, OTC

15285, Houston, Texas, May, 2003.

[88] Anagnostopoulos, P. (Editor), Flow-Induced Vibrations in Engineering Practice, Ashurst, UK, WIT

Press, 2002

[89] Andersen, K. H., Kleven, A. and Heien, D. (1988), “Cyclic Soil Data for Design of Gravity Structures,”

ASCE, Journal of Geotechnical Engineering, Vol. 114, GT5, pp. 517 to 539

[90] Andersen K. H. and Lauritzen, R. (1988), “Bearing Capacity for Foundations with Cyclic Loads,”

ASCE, Journal of Geotechnical Engineering, Vol. 114, No. GT5, pp. 540 to 555

[91] Andersen, K. H. (1991), Foundation Design of Offshore Gravity Structures, Chapter 4, Cyclic Loading

of Soils. From Theory to Design, Edited by M. P. O’Reilly and S. F. Brown, Blackie and Son Ltd.,

Glasgow and London

[92] Andersen, K. H. and Jostad, H. P. (1999), “Foundation Design of Skirted Foundations and Anchors in

Clay,” 31st Annual Offshore Technology Conference, OTC 10824, Houston, Texas, May

[93] Andersen, K. H. and Jostad, H. P. (2002), “Shear Strength Along Outside Wall of Suction Anchors in

Clay after Installation,” Proceedings of 12th ISOPE Conference, Kyushi, Japan, May 26 to 31

[94] Baar, J. J. M., Howell, C. T., Mercier, R. S. and Rodenbusch, G., “Long-term Response of Tension leg

Platform,” Proceedings of Seventh International Offshore and Polar Engineering Conference (ISOPE),

Honolulu, Hawaii, May, 1997

[95] Banon, H., Toro, R. G., Jefferys, E. R., and R. S. De, “Development of Reliability-Based Global Design

Equations for TLPs,” OMAE, Houston, Texas, February 1994

[96] Barltrop, N. D. P.; Adams, A.J., Dynamics of Fixed Marine Structures, Third Edition, Butterworth-

Heinemann, Oxford, 1991

[97] Bearman, P. W., Wind Loads on Structures in Turbulent Flow, The Modern Design of Wind-Sensitive

Structures, Construction Industry Research and Information Association, London, UK, pp. 42 to 48,

1971

[98] Bearman, P. W., “Vortex Shedding from Oscillating Bluff Bodies,” Annual Review of Fluid Mechanics,

Vol.16, pp. 195 to 222, 1984

[99] Bergdahl, L. and Johannson, M., “Time Simulations of the Motion of a Tension Leg Platform,”

Proceedings of Fifth International Conference on the Behavior of Offshore Structures (BOSS ’88),

Trondheim, Norway, June 1988

[100] Blevins, R. D., Flow-Induced Vibrations, Van Nostrand Reinhold, New York, 1990

Provided by IHS under license with API

Licensee=Shell Global Solutions International B.V. Main/5924979112, User=Low, Ko

Not for Resale, 01/31/2011 00:10:44 MST

No reproduction or networking permitted without license from IHS

--``,`,```,,,``,`,``,,,,,,,,,,`-`-`,,`,,`,`,,`---
