Table 6.5 Theoretical hardness factors computed from

the displacement damage function D(E) normalized to the

1 MeV neutrons value (from [Leroy and Rancoita (2007)]).

Particle κ

theo

[D(E)/95 MeV mb]

1 MeV neutrons 1.00

7 MeV protons 7.40

8 MeV protons 5.90

9 MeV protons 5.10

10 MeV protons 4.50

∗

24 GeV/c protons 0.62

∗

The value for the 24 GeV/c protons is an experimental

value extracted from [Rose Collab. (2001)].

re-normalized to 20

◦

C [Sze (1981)]. By re-writing Eq. (4.134) [see Sect. 4.3.2],

the leakage current per unit volume (I

vol

) as a function of ﬂuence (Φ) is given

by (e.g., [Kraner, Li and Posnecker (1989)]):

vol

(Φ) − I

v ol

(0) = α Φ, (6.161)

where α is the radiation-induced reverse current damage constant [in Eq. (4.134),

v ol

(Φ) = I

r,irr

v ol

and I

vol

(0) = I

vol

]. It is found [Bechevet, Glaser, Houdayer,

Lebel, Leroy, Moll and Roy (2002)] that the values of the α parameter extracted

after heating the detectors for 4 minutes at 80

◦

C show good agreement between SP

and PM detectors.

The irradiation induced change on the α parameter as a function of the heating

temperature (T

) and heating time (t) for detectors (guard ring connected) is given

by the phenomenological expression [Moll (1999)]:

t/T

= α

exp

−

+ α

− β ln

. (6.162)

Equation (6.162) is a convenient parametrization which does not pretend to be

based on a physical model [Moll (1999)]. Fitting Eq. (6.162) to the experimental

data [Bechevet, Glaser, Houdayer, Lebel, Leroy, Moll and Roy (2002)], one can see

that the decrease of the leakage current with annealing is more signiﬁcant for the

SP detectors as compared to the PM detectors.

In summary, the results of PM detectors studies show that detectors produced

by planar MESA technology have a satisfactory performance as particle detectors

operated in high radiation environment. MESA planar silicon detectors were ex-

posed to low energy protons in order to extract the evolution of the eﬀective dop-

ing concentration and leakage current as a function of ﬂuence, up to a ﬂuence of

5×10

p cm

−2

. The detectors have been heated at 80

◦

C in order to study the ageing

of the detectors. Altogether, the behavior under irradiation of PM and SP detectors

is comparable, though the decrease of the leakage current with annealing is more

January 9, 2009 10:21 World Scientiﬁc Book - 9.75in x 6.5in ws-bo ok975x65˙n˙2nd˙Ed

Solid State Detectors 531

-2

-1

1 10 10

7 MeV

8 MeV

9 MeV

10 MeV

24 GeV/c

Proton fluence (10

p cm

-2

)

Leakage current (µA/cm

)

Fig. 6.46 The leakage current (in µA/cm

) as a function of the proton ﬂuence (Φ in units of

p cm

−2

) after heating for 4 minutes at 80

◦

C (reprinted from Nucl. Instr. and Meth. in

Phys. Res. A 479, Bechevet, D., Glaser, M., Houdayer, A., Lebel, C., Leroy, C., Moll, M. and

Roy, P., Results of irradiation tests on standard planar silicon detectors with 7–10 MeV protons,

487–497, Copyright (2002), with permission from Elsevier).

signiﬁcant for the SP detectors, particularly after inversion. Measurements of the

charge collection eﬃciency (CCE) as a function of ﬂuence were performed [Chren

et al. (2001)]. At a ﬂuence Φ ≈ 10

particles cm

−2

, the charge carrier lifetime

degradation due to trapping with increased ﬂuence is responsible for a charge col-

lection deﬁcit of about 12% and about 10% for β-particles incident on MESA and

standard planar detectors, respectively. For α-particles incident on the front side,

one ﬁnds a deﬁcit of 20% for MESA and 25% for standard planar detectors. The

deﬁcit increases to 30% and 35% for α-particles incident on the back side of MESA

and SP detectors, respectively. These results are in good agreement with existing

direct measurements ([Casse et al. (1999a); Leroy et al. (1994)], see also [SICAPO

Collab. (1994b,c)]).

6.8.3 Irradiation with Low-Energy Protons and Violation of NIEL

Scaling in High-Resistivity Silicon detectors

Standard planar silicon detectors were exposed [Bechevet, Glaser, Houdayer, Lebel,

Leroy, Moll and Roy (2002)] to low-energy protons in order to extract the evolution

of the eﬀective doping concentration and leakage current as a function of ﬂuence,

up to a ﬂuence of 7 × 10

p/cm

. These measurements were part of a study done

for the LHC. The radiation hardness of standard planar silicon detectors exposed

January 9, 2009 10:21 World Scientiﬁc Book - 9.75in x 6.5in ws-bo ok975x65˙n˙2nd˙Ed

532 Principles of Radiation Interaction in Matter and Detection

-2

-1

1 10 10

7 MeV

8 MeV

9 MeV

10 MeV

24 GeV/c

(10

p cm

-2

)

Leakage current (µA/cm

)

Fig. 6.47 The leakage current (in µA/cm

) as a function of 1 MeV neutron equivalent ﬂuence

(Φ

= Φ ×κ

in units of 10

p cm

−2

) after heating for 4 minutes at 80

◦

C (reprinted from Nucl.

Instr. and Meth. in Phys. Res. A 479, Bechevet, D., Glaser, M., Houdayer, A., Lebel, C., Leroy,

C., Moll, M. and Roy, P., Results of irradiation tests on standard planar silicon detectors with

7–10 MeV protons, 487–497, Copyright (2002), with permission from Elsevier).

to low-energy protons was tested and the results were compared to those obtained

from the irradiation of similar material with 24 GeV/c protons. The goal of this

study was also to understand the limits of NIEL scaling and therefore the limits for

predictions of radiation damage produced by protons with diﬀerent energies. The

resistivity of the detectors used for the study was 2 kΩcm and the proton energies

used were 7, 8, 9, 10 MeV. No proton of energy lower than 7 MeV was used to be

sure that these protons were not stopped in the 300 µm (295 ±5 µm) thick detectors

(Table 6.4 and [Berger, Coursey, Zucker and Chang (2005)]).

Since the LHC experiments will be in operation for at least 10 years, it is nec-

essary to study the long term behavior of silicon detectors to be used in these

experiments when exposed to high level of radiations.

The detectors were heated at 80

◦

C for up to 17 hours in order to extract the

damage parameters necessary to simulate the detectors ageing during 10 years of

operation of the LHC experiments. A word of explanation is needed to understand

the choice of the temperature of 80

◦

C. Heating detectors after their irradiation

has become a standard procedure. This procedure allows the comparison of particle

irradiations without the inﬂuence of the irradiation time and the samples irradiated

at diﬀerent facilities can be considered as being in the same annealing state. The

eﬀective doping concentration, N

eﬀ

, varies with the diode ageing. At ﬁrst, N

eﬀ

(and

then V

) decreases with time after being heated. This period of beneﬁcial annealing
