Note that the absolute values of the GB diffusivity P
Ni
in NiAl are appre-
ciably smaller than those in Ni
3
Al and pure Ni at the same temperatures.
4.6.5 Fe
3
Al
Fe GB diffusion in the Fe
3
Al compound was investigated in the
extended temperature interval 733 to 1065 K.
[110]
The temperature depend-
ence of P
Fe
is presented in Fig. 4.23. The compositional dependence of
Fe GB diffusivity has not been studied. Tokei et al. found
[110]
that the
A2 B2 transition does not remarkably affect the GB diffusion, although
a negative deviation of the P
Fe
values from the otherwise linear Arrhenius
dependence is indicated below the B2 D0
3
transition temperature (see
Fig. 4.23). These deviations are not caused by a hypothetical transition
from the B to the C GB diffusion regime, since the B regime conditions
were realized even at the lowest temperature.
[110]
The smaller diffusivities
of GBs in the D0
3
phase field suggest a higher degree of order in the GB
region of the corresponding phase in comparison with the B2 structure.
Atomistic calculations of defect formation and migration enthalpies
would give more insight into this problem.
It was also proposed
[110]
that the GB segregation of Al in Fe
3
Al can
modify the order-disorder transition temperature in GBs as compared to
the bulk transition temperature, especially for the A2 B2 transition.
4.7 Summary
Self-diffusion of the transition metal component in Ni
3
Al, Ti
3
Al, and
TiAl mainly occurs by nearest neighbor jumps via vacancies in the transi-
tion metal sublattice (sublattice diffusion mechanism). This mechanism
(that is, next–nearest neighbor jumps of Ni atoms) does not dominate in
NiAl. The triple-defect mechanism produces the main contribution to dif-
fusion in the near-stoichiometric NiAl alloys. Under specific conditions
(high temperatures in TiAl, T 1450 K, or large Ni content in NiAl,
c
Ni
55 at.%), the antistructure bridge mechanism also becomes impor-
tant in these intermetallics.
The transition metal sublattice diffusion mechanism superimposed by
the ASB mechanism governs Al diffusion in Ni
3
Al, Ti
3
Al, and TiAl. Ga,
which dissolves exclusively on the Al sublattice in Ni and Ti aluminides,
is a suitable solute to simulate Al diffusion in these compounds because it
diffuses by the same mechanisms as Al. Al diffusion in near-stoichiometric
NiAl alloys mainly occurs by the triple-defect mechanism, and the ASB
mechanism dominates Al diffusion in Al-rich compositions.
232 DIFFUSION PROCESSES IN ADVANCED TECHNOLOGICAL MATERIALS
Chapter-04.qxd 11/29/04 6:36 PM Page 232
DIFFUSION IN INTERMETALLIC COMPOUNDS, HERZIG, DIVINSKI 233
91011121314
T
-1
[10
-4
K
-1
]
10
-25
10
-24
10
-23
10
-22
10
-21
10
-20
10
-19
P [m
3
s
-1
]
8001100
900
1000
T [K]
A2
D0
3
B2
Figure 4.23 Arrhenius plot of Fe grain boundary diffusion in Fe
3
Al.
[110]
The tem-
perature intervals of the A2, B2, and D0
3
phases are indicated.The solid line rep-
resents an Arrhenius fit of the data measured in the A2 and B2 phase regions.
Chapter-04.qxd 11/29/04 6:36 PM Page 233
Bulk self-diffusion in the antistructure-defect-type Ni and Ti alu-
minides (Ni
3
Al, Ti
3
Al, and TiAl) reveals only a marginal compositional
dependence, whereas a pronounced compositional dependence of D
Ni
is
observed in the triple-defect-type NiAl phase. This behavior is related to
the fact that the sublattice diffusion mechanism operates mainly in Ni
3
Al,
Ti
3
Al, and TiAl.
Self-diffusion of the transition metal component in the closed-packed
Ni and Ti aluminides, if measured at the same reduced temperature,
decreases systematically when changing from pure metal to A
3
B and to
AB compound.
Grain boundary self-diffusion in closed-packed A
3
B compounds
(Ni
3
Al and Ti
3
Al) reveals a distinct compositional dependence, despite a
marginal compositional dependence of the bulk self-diffusivity in these
compounds. The deviation from the stoichiometric composition in these
alloys produces different effects on the transition metal GB diffusion in
Ni
3
Al and Ti
3
Al: An increase of P
Ni
and a decrease of Q
Ni
gb
in Ni
3
Al, and
the opposite in Ti
3
Al (a decrease of the P
Ti
values and an increase of Q
Ti
gb
in the Al-rich compositions).
