The Author’s Preface
This book deals with the fundamental principles of electrodynamics, i .e. the theory
of electromagnetic fields as given by Maxwell's equations. It is an outgrowth from
the lectures, which the author has been giving to the students of electrical
engineering at the University of Stuttgart, Germany, for approximately a quarter of
a century. For the textbook, the contents of the lectures have been supplemented by
a chapter on numerical methods for the solution of boundary and initial value
problems, which provides a rough first survey over the methods available only,
without going into details. Furthermore, there are several appendices devoted to
some more special topics, as among others to the problem of the possibility of an
extremely small but nonzero restmass of the photon, which would lead to Proca’s
equations, a modified version of Maxwell’s equations; to the important question of
eventually existing magnetic monopoles; to the deeper meaning of the
electromagnetic potentials in view of quantum mechanics and the Bohm-
Aharonov-effects. The last appendix covers a brief survey of special relativity,
because this, in principle, is an essential part of electrodynamics, which is
inevitably needed for its real understanding.
The treatment is based on Maxwell’s equations from the beginning. They are
described and explained in Chapter 1. The following chapters are devoted to
electrostatics; to the important mathematical tools of electromagnetic field theory
(method of separation of variables using cartesian coordinates, cylindrical
coordinates, and spherical coordinates; conformal mapping for plane problems); to
stationary current density fields; to magnetostatics; to quasi stationary time
dependent problems as field-diffusion, skin effect etc.; and finally electromagnetic
waves and dipole radiation. Everything in these chapters is derived from Maxwell's
equations, except the additionally necessary assumptions characterizing various
media, their conductivity, polarizability, and magnetizability.
The basic concepts of vector analysis are also developed from the beginning
together with Maxwell’s equations. The divergence (div) is defined as the small
volume limit of the surface integral (flux) of a vector field and the rotation (curl) as
small surface limits of three line integrals (circulations) of a vector field. These
definitions immediately clarify the plausible meaning of both of these operators of
vector analysis. The divergence being the volume density of sources or sinks, the
rotation being the three dimensional surface density of circulation. The integral
theorems of Gauss and Stokes are immediately plausible consequences of these
definitions also. This procedure provides an easy and well comprehensible access
to the realm of vector analysis. It also very clearly demonstrates the physical
meaning of Maxwell’s equations. Helmholtz’s theorem (presented in one of the
appendices) teaches us that each vector field is completely defined by its
divergence and its rotation. So it is obvious that we need four equations to describe
electric and magnetic fields, two for their sources and sinks and two for their
circulations. Thus, Maxwell’s equations, often considered to be almost
incomprehensible, are hoped to become really plausible.
